Basic HTML Version
A-1S20S-R-2
A-1S20S-L-4
Item Part Number
1.
B-131 04-R
*
B-13104-L
2.
SW-1A-193
3.
4701-00002-00
4.
4105-01019-10
5.
4008-01079-05
6.
4701-00003-QO
7.
01-9375
8.
20-6516
9.
4010-01066-06
10.
4701-00004-00
11.
A-12111
12.
FL-11629
a)
03-7066-5
*
FL-15411
13.
01-7695
14.
4006-01017-04
15.
10-364
16.
B-13882-R
*
B-13882-L
a)
B-13884-R
*
B-13884-L
b)
A-10656
c)
02-4179
d)
4010-01086-14
e) 4700-00023-00
f)
4701-00004-00
g)
4410-01132-00
17.
23-6577
18.
03-7568
19.
4006-01005-06
20.
4406-01117-00
Fliptronic
II
Flipper
Assy.
Fliptronic
II
Flipper
Assy.
Description
Flipper Base Assy, Right
Flipper Base Assy, Left
Switch Assembly
Lockwasher, #6 Split
Sh. Metal Screw, #5
x
5/8
P-RH-A
Mach. Screw, 8-32
x
5/16
H-SOC
Lockwasher, #8 Split
Switch Mounting Bracket
Speednut, Tinnerman
• Cap Screw, 10-32
x
3/8,
SH
Lockwasher, #10 Split
Flipper Stop Assembly
Flipper Coil (Blue)
Coil Tubing
Flipper Coil (Orange)
Solenoid Bracket
Mach. Screw, 6-32 x
1/4
P-RH-S
Spring
Crank Link Assembly, Right
Crank Link Assembly, Left
Flipper Crank Assembly, Right
Flipper Crank Assembly, Left
Flipper Link Assembly
Link Spacer Bushing
Cap Screw, 10-32 x
7/8
SH
Flatwasher, 5/8 x 13/64 x 16ga.
Lockwasher #10 Split
Nut, 10-32 ESN
Bumper Plug, 5/8"
Flipper Bushing
Mach. Screw, 6-32 x 3/8 P-PH
Nut, 6-32 Hex.
Associated Parts for Left
&
Right Flippers:
21.
23-6535
22.
20-9250-5
Flipper Rubber (Black)
Flipper & Shaft (White)
A-1S843
Electronic Flipper
Assy.
(Parts listed replace same items of
A-1S20S-R)
Item Part Number
Description
1.
B-13104-R
Flipper Base Assy, Right
15.
Not Used
16.
B-10655-R
a)
B-1 0657-R
23.
"'*
10-376
Crank Link Assembly, Right
Flipper Crank Assembly
Spring
Flipper Notes:
1.
'" Items for Left Flipper Assembly ONLY.
2.
"'*
Not Shown.
3.
Each Flipper Assembly is mounted beneath the
playfield, in conjuction with the Plastic Flipper & Shaft,
and Flipper Rubber on the upper side of the playfield.
4.
With the flipper, in the non-activated position,
the E.O.S. Switch contacts must have a gap of
.062 (±.015) inch. When flipper is activated switch
must close.
5.
Any adjustment of the E.O.S. Switch must be made
at a minimum distance of 0.25 inch from the switch
body.
6.
Longer blade of E.O.S. Switch must be straight.
Gap adjustment is done by adjusting shorter
blade.
7.
All moving elements of the assembly must operate
freely without any evidence of binding.
8.
Apply Loctite™ 242 when reataching screws to the
Flipper Stop Assembly, the Solenoid Bracket, and the
Flipper Bushing.
WHITE WATER 2-20
