A-12742-50018 WPC CPU Board
Part Number
Designator
Description
5010-09034-00
R14-R22, R27-R42, R86,
Resistor, 10Kn,
1/4w, 5%
R90,R94,R98
5010-09085-00
R1,R2,R4,R93,R96,R97
Resistor, 1.5Kn,
1/4w, 5%
5010-09314-00
R52, R54, R56, R58, R60,
Resistor, 1.2Kn,
1/4w, 5%
R62, R64, R66, R75-R82
5010-09358-00
R3, R43-R51, R53, R55, R57,
Resistor, 1Kn,
1/4w, 5%
R59, R61, R63, R65, R67-R74,
R84
5010-09416-00
R5-R8, R12, R13, R87-R89
Resistor, 470n,
1/4w,
5%
5010-09534-00
W1, W4, W7, W13 - W18
Resistor, on
5010-10258-00
R95,R99
Resistor, .01Jlfdn,
1/4w, 5%
5010-10989-00
R92
Resistor, 470Kn,
1/4w, 5%
!
5010-12104-00
R91
Resistor, 22Jlfd,
1/4w, 5%
5019-09362-00
SIP 1
SIP, 9R, 10-pin, 4.7Kn, 5%
5040-08986-00
C31
Capacitor, 100Jlfd, 10v (±20%)
5043-08980-00
B
Capacitor, .01Jlfd, 50v, (+80, -20%)
5043-09030-00
C27
Capacitor, 0.047Jlfd, 50v (±20%)
5043-09065-00
C3 - C26
Capacitor, 470pfd, 50v (±20%)
5043-09491-00
C2, C29, C30, C34
Capacitor, 22pfd, 1KV, (±10%)
5043-09492-00
C28
Capacitor, 100pfd, 50v, (±10%)
5043-09845-00
C32,C33
Capacitor, 1KP, 50v, (±20%)
5070-08919-00
02 - 018
Diode, 1N4148, 150MA
5070-09266-00
01,025
Diode, 1N5817, 1.0A.
5160-10269-00
Q1
Transistor, 2N3904, NPN
5162-12422-00
U20
IC, ULN, 2803A
5281-09308-00
U3
IC, 74LS245, Octal Bus Trncv
5281-09486-00
U14
IC, 74LS374, 80 F/F
5281-09851-00
U5
IC, 74LS14, SMTITRG
5281-09867-00
U1, U2, U7
IC, Octal Buffer, 74LS244
5281-10182-00
U11, U12, U13, U15
IC, 74LS240 Driver-
5284-12651-00
U21
IC,4584
5340-12278-00
U8
StRAM 2064
5370-12272-00
U16 - U19
IC, LM339, Quad. Comp
5370-12687-00
U10
MC, 34064 Reset Chip
5520-10438-00
X2
Crystal, 8.0MHz.
5520-12084-00
X1
Crystal 32.768 KHz
5551-09822-00
L1
ILN, 4.7 UH 3A
5671-09019-00
019 - 021
OSPLLEO RED
5700-08985-00
U4
Socket, IC 40P, .6"
5700-12088-00
U6
Socket, IC 32P, .6"
5700-12424-00
U9
Socket, 84 Pin PLCC
5791-10850-00
J201,J204
Connector, 26-pin Header Str Sq.
5791-10862-07
J210
Connector, 7-pin Header Str Sq.
5791-12461-08
J212
Connector, 8-pin Header Str Sq.
5791-12461-09
J206 - J209
Connector, 9-pin Header Sq. pin
5791-12461-12
J205
Connector, 12-pin Header Sq. pin
5791-12516-00
J202, J211
34 Hen 2x17 STR
5881-09021-00
B1 - B3
Battery Holder" AA"
5048-11033-00
C50
Capacitor,0.022Jlf, 10v
A-5343-50018-1
U6
Game PROM Assembly
5410-12426-00
U9
WPC-89 ASIC
5400-10320-00
U4
IC MPU 68B09E
5880-09022-00
B1 - B3
Battery, Alkaline, 1.5v ("AA")
WHITE WATER 2-8
