Backbox
Assembly
1
)-__JlllU~~~~~~1111l-----@
1-------------------------,
I
I
I
I
I
__________________
L
~l
j
11bJ------~(
0 ) '-
1_1_d
~
~;A.l
~~ ~?
~r-----~
""C7
11
c
.7
""1----i23
Item Part Number
Description
Item Part Number
Description
1.
01-6645
Venting Screen
16.
01-10889
Waterfall Light Shield
2.
B-10686-1
Knocker & Bracket Assy.
17.
A-15765
8-Lamp Board Assembly
3.
A-12497
Upper Insert Bd Hinge Assy.
18.
A-15812
Support & Waterfall Assy.
4.
A-14092-3
Mounting Plate Assembly
19.
A-15761
Chase Light PC Board
5.
A-12498
Lower Insert Bd Hinge Assy.
6.
A-12697-1
Power Driver Assembly
Ribbon Cables:
7.
A-12738.-500 18
WPC Sound Board
8.
A-12742-50018
WPC CPU Board
20.
5795-12653-03
Ribbon Cable, 3"
9.
A-15803-50018
Backbox Assembly
21.
5795-13018-00
Ribbon Cable, 22"
10.
01-9047
Insert Stop Bracket
22.
5795-1 0938-14
Ribbon Cable, 14"
11.
A-15757
Speaker / Display Assy.
23.
5795-12838-30
Ribbon Cable, 30·
a)
5555-12924-00
Speaker, 4Q, 15w
b)
5555-12856-00
Speaker, 5-1/4", 4Q, 25w
Miscellaneous Parts:
c)
5045-12914-00
Cap., 10J.lfd., 50v, (±20%)
d)
5901-12784-00
Dot Matrix Display/Driver Bd.
A-8552-50018
Tempered Backglass Assy.
12.
A-14039
Dot Matrix Contoller Board
08-7456
Backbox Glass: 27" x 18-7/8"
13.
A-13379
Lock & Plate Assembly
31-1357-50018
Screened Translight
a)
20-9637
Lock & Cam Kit
03-8228-2
Glass Channel Top (1)
14.
50018-IN
Insert Board
03-8228-3
Glass Channel Edge (2)
15.
A-15472
Fliptronic II Board
03-8229-1
Glass Lift Channel (1)
WHITE WATER 2-4
