A.S 01
A.S Printer Adjustments
(optional board required)
A.S 02
A.S 03
A.S 04
A.S
05
A.S 06
.,
Column Width
The column width to be printed. Range: 22 to 80.
Lines Per Page
The amount of lines per page. Range: 20 to 80.
Pause Every Page
Choose whether the printer pauses at the end of a page.
YES
The printer does pause.
NO
The printer doesn't pause.
Printer Type
Select the type of printer: Parallel, Serial or ADP.
Serial Baud Rate
Select which baud rate to use for serial or ADP communications (bit rate): 300, 600, 1200,
2400, 4800, or 9600.
Serial D.T.R. (Data Terminal Ready)
When a serial printer is used, this line may be connected to a printer output line signaling
that the printer is busy.
Normal
Normal D.T.A. signal goes low to indicate the printer is
not ready.
Inverted D.T.A. (busy) signal goes high to indicate the
printer is not ready.
Inverted
Ignore
D.T.A. signal is ignored.
WHITE WATER 1-33
