T.12 Flipper Coil Test
The Flipper Coil Test has three modes, Repeat, Stop, and Run.
Only one Flipper should pulse at a time. The system has detected a problem if; more then one
flipper pulses, a flipper comes On and stays On or, during the Repeat and Run mode, no flipper
pulses.
Repeat
The Repeat mode pulses a single flipper. After entering this test, flipper coil 01 shows in
the display and the corresponding coil activates.
Press the Up or Down button to cycle
through the flipper coils, one at a time. The same solenoid pulses until the Up or Down
button is pressed.
Either press the Escape button to return to the Test Menu, or press
the Enter button to move to the next mode.
Stopped
Running
The Stopped mode halts the Flipper Coil Test. Press Enter during the Repeat mode and
the test stops. No coils should be activated while the test is stopped.
Either press the
Escape button to return to the Test Menu, or the Enter button to move to the next mode.
The Running mode cycles through the flippers automatically.
The display shows the
name and number of the flipper coil currently being pulsed.
,.
T. 13 Ordered Lamps Test
The number assigned to each lamp indicates the lamp's
position in the matrix. The number on the left indicates the column.
The number on the right
indicates the row. Example - Lamp 23 means 2nd column, 3rd row.
This test checks each lamp circuit individually.
Press the Up or Down button to cycle through the
lamps. Lamps light in a clock-wise or counter clock-wise direction starting from the bottom of the
playfield.
Direction depends on which button, Up or Down, is pressed.
For each name and
number that is shown in the display the corresponding lamp should light. Any other results
indicates the system has detected a problem.
T.14 Bigfoot Test
The Bigfoot Test has three options: 1} Head Motor Test; 2} Head
Opto Test; 3} Head Position Test. Press the Up or Down button to select an option, (an option
flashes when it is selected).
Press the Enter button to begin. Press the Escape button to stop
the option and return to the Bigfoot Test Menu.
1}
Head Motor Test
The head rotates continuously.
The direction CW (clock-wise) or CCW
(counter clock-wise) shows on the display. Press the Up or Down button
to change the direction of the head rotation.
The head rotates continuously.
The display shows two boxes, one for
Opto 1 and the other for Opto 2. When the switch makes, an "X" appears
in the appropriate box. When the switch breaks the "X" disappears.
The head turns intermittently.
The display shows the position of the
head.
2} Head Opto Test
3} Head Position Test
T.15 Backbox Test
Each bulb on the top of the backbox , near the WHITE WATER
sign, is turned On and Off in a sequence.
In the first sequence, each bulb turns On and remains
On until the last one is lit. Then, they all turn Off. In the second sequence, each bulb turns On
and Off individually.
NOTE:
Replace bulbs on the top of the backbox with #194 bulbs Only!
Part Number 24-8831
WHITE WATER
1-16
