Power Driver Board
Interboard Wiring
r>
J101 -1 Red (9VAC) from xformer secondary
J101 - 2Red (9VAC) from xformer secondary
J101 -
3N/C
J101 - 4Blue-White (13VAC) from xformer secondary
J101 - 5Blue-White(13VAC) loop from J101-4
J101 - 6Blue-White (13VAC) from xformer secondary
J101 - 7Blue-White (13VAC) loop from J101-6
J102 -1 White-Red (16VAC) loop from J102-2
J102 - 2 White-Red (16VAC) from xformer secondary
r
J102 - 3 White-Red (16VAC) loop from J102-4
J102 - 4 White-Red (16VAC) from xformer secondary
J102 - 5 Black-Yellow (SWAC) loop from J102-6
J102 - 6 Black-Yellow (SWAC) from xformer secondary
J102 - 7
N/C
J102 - 8 Black-Yellow (S1AC) loop from J102-9
J102 - 9 Black-Yellow (S1VAC) from xformer secondary
J103 -1
N/C
J103 - 2
N/C
J103 - 3
N/C
J103 - 4
N/C
J104 - 1 White-Blue (SOVAC)to Fliptronic II Board J901-3
,~ J104 - 2 White-Blue (SOVAC)to Fliptronic II Board J901-1
J104 - 3
N/C
J104 - 4
N/C
J104 - 5
N/C
J105 -1
N/C
J105 - 2
N/C
J105 - 3
N/C
J105 - 4 White-Red (20VAC) to Chase Lamp Board J1-2
J105 - 5 White-Red (20VAC) to Chase Lamp Board J1-1
J106 -1 NlC
J106 - 2
N/C
J106 - 3
N/C
J106 - 4
N/C
J106 - 5 Red-White (+20V) to backbox flashlamps
J107 -1 NlC
J107 - 2 Violet-Orange (+50V) to coils
J107 - 3 Violet-Yellow (+50V) to coils
J107 - 4
N/C
J107 - 5
N/C
J107 - 6 Red-White (+20V) to playfield flashlamps
J108 -1
N/C
J108 - 2
N/C
J108 - 3
N/C
J109 -1 NlC
J109 - 2
N/C
J109 - 3
N/C
J109 - 4
N/C
J109 - 5 NlC
J109 - 6 NlC
J109 -7 NlC
J110 -1 NlC
J110 - 2 NlC
J110 - 3
N/C
J110 - 4 NlC
J110 - 5 NlC
J110 - 6
N/C
J110 -7
N/C
J110 - 8 NlC
J110 - 9
N/C
J111 -1
N/C
J111 - 2
N/C
J111 - 3 NlC
J111 - 4
N/C
J111 - 5
N/C
J112 - 1 White-Green (9.8VAC) from xformer secondary
J112 - 2 White-Green (9.8VAC) loop from J112-1
J112 - 3 White-Green (9.8VAC) from xformer secondary
J112 - 4 NlC
J112 - 5 White-Green (9.8VAC) loop from J112-3
J113, 34-pln Ribbon Cable (data) Tolfrom CPU J211
J114 -1 Gray-Green (+12V) to J210-6,7; J90,4-2
J114 - 2 Gray-Green (+12V) to J210-6,7; J904-2
J114 - 3 Gray (+SV) to J210-4,S; JS02-1,3; J904-1
J114 - 4 Gray (+5V) to J210-4,5; J502-1,3; J904-1
J114 - 5 Black (Grd) to J210-1,3; JS02-4,5; J904-4,5
J114 - 6 NlC
J114 - 7 Black (Grd) to J210-1,3; JS02-4,5; J904-4,5
J115 -1
J115 - 2
J115 - 3
J115 - 4
J115 - 5
J115 - 6
J115 -7
J115 - 8
J115 - 9
J115 -10
J115 -11
J115 -12
Yellow-White (6.8VAC) from xformer secondary
Yellow (6.8VAC) from xformer secondary
Yellow (6.8VAC) loop from J115-2
Yellow (6.8VAC) from xtormer secondary
Yellow (6.8VAC) loop from J115-4
Yellow (6.8VAC) from xformer secondary
Yellow-White (6.8VAC) from xformer secondary
Yellow-White (6.8VAC) loop from J11S- 7
NlC
Yellow-White (6.8VAC) from xformer secondary
Yellow-White (6.8VAC) loop from J11S-10
Yellow-White (6.8VAC) from xformer secondary
WHITE WATER 3-39
