Fliptronic II Board
Interboard Wiring
1
I
0 0 0 0 0 0 0 0 0
*
0 0 0
113
J902
J901 - 1
J901 - 2
J901 - 3
J901 - 4
J901 - 5
J904
~L-I
J_90_3
I:
10
0
*
0 0
I
White-Blue (50VAC) from Power Driver Board J104-2
White-Blue (50VAC) loop from J901-1
White-Blue (50VAC) from Power Driver Board J104-1
N/C
White-Blue (50VAC) loop from J901-3
J902 -1 N/C
J902 - 2 N/C
J902 - 3 N/C
J902 - 4 Orange-Violet (holding) upper right flipper coil
J902 - 5 N/C
J902 - 6 Black-Yellow (power) upper right flipper coil
J902 - 7 Orange-Blue (holding) lower left flipper coil
J902 - 8 N/C
J902 - 9 Blue-Gray (power) lower left flipper coil
J902 -10 N/C
J902 - 11 Orange-Green (holding) lower right flipper coil
J902 -12 N/C
J902 - 13 Blue-Violet (power) lower right flipper coil
J903, 34-pln Ribbon Cable (data) To/from J202; J601; J506
J904 - 1 Gray (+5V) from Power Driver Board J114-3,4
J904 - 2 Gray-Green (+12V) from Power Driver Board J114-1,2
J904 - 3
N/C
J904 - 4 Black (Grd) from Power Driver Board J114-5,7
J904 - 5 Black (Grd) from Power Driver Board J114-5,7
r-~
0
0
*
"-
0
0
0
Ol
-,
0
0
~
°
~kn
r
-rn° -
o
0
~ *
o
",
J905 - 1 Blue-Violet to right opto switch board J1-1
J905 - 2 Blue-Gray to left opto switch board J1-1
J905 - 3 Black-Yellow to right opto switch board J1-2
J905 - 4 N/C
J905 - 5 Black-Blue to left opto switch board J1-2
J905 - 6 Orange (Grd) to left opto switch board J1-3
::.
J906 -1 Black-Green to lower right EOS switch
J906 - 2 N/C
J906 - 3 Black-Blue to lower left EOS switch
J906 - 4 Black-Violet to upper right EOS switch
J906 - 5 N/C
J906 - 6 Orange (Grd) to EOS switches
J907 -1 N/C
J907 - 2 N/C
J907 - 3 N/C
J907 - 4 Blue-Yellow (+50V) to upper right flipper coil
J907 - 5 Blue-Yellow (+50V) loop from J907-4
J907 - 6 Gray-Yellow (+50V) to lower left flipper coil
J907 -7 Gray-Yellow (+50V) loop from J907-6
J907 - 8 Blue-Yellow (+50V) to lower right flipper coil
J907 - 9 Blue-Yellow (+50V) loop from J907-8
