CPU Board
Interboard Wiring
J201, 26-pin Ribbon Cable (data)
To/from
J602
J202, 34-pin Ribbon Cable (data)
To/from
J903; J506; J601
J203 - Not Used
J204 - Not Used
J205 -1 Orange-Brown (ded. sw. row 1) to Coin Door Brd J1-14
J205 - 2 Orange-Red (ded. sw. row 2) to Coin Door Brd J1-13
J205 - 3 Orange-Black (ded. sw. row 3) to Coin Door Brd J1-12
•
J205 - 4 Orange-Yellow (ded. sw. row 4) to Coin Door J1-17
J205 - 5 N/C
J205 - 6 Orange-Green (ded. sw. row 5) to Coin Door Brd J1-11
J205 -7 Orange-Blue (ded. sw. row 6) to Coin Door Brd J1-10
J205 - 8 Orange-Violet (ded. sw. row 7) to Coin Door Brd J1-9
J205 - 9 Orange-Gray (ded. sw. row 8) to Coin Door Brd J1-8
J205 - 10 Black (Grd) to Coin Door Brd J1-15
J205-11 N/C
J205 - 12 Orange-White (sw. enable) to Coin Door Brd J1-18
J206 -1 N/C
J206 - 2 N/C
J206 - 3 N/C
J206 - 4 N/C
J206 - 5 N/C
J206 - 6
N/C
J206 -7 N/C
J206 - 8 N/C
J206 - 9 N/C
J207 - 1 Green-Brown (sw. col. 1) to playfield switches
J207 - 2 Green-Red (sw. col. 2) to playfield/cabinet switches
J207 - 3 Green-Orange (sw. col. 3) to playfield switches
J207 - 4 Green-Yellow (sw. col. 4) to playfield switches
J207 - 5 Green-Black (sw. col. 5) to playfield switches
J207 - 6 Green-Blue (sw. col. 6) to playfield switches
J207 -7 Green-Violet (sw. col. 7) to playfield switches
J207 - 8
N/C
J207 - 9 Green-Gray (sw. col. 8) to playfield switches
-;
J208 -1 N/C
J208 - 2 N/C
J208 - 3 N/C
J208 - 4 N/C
J208 - 5 N/C
J208 - 6 N/C
J208 -7 N/C
J208 - 8 N/C
J208 - 9 N/C
J209 - 1 White-Brown (sw. row 1) to playfield switches
J209 - 2 White-Red (sw. row 2) to playfield switches
J209 - 3 White-Orange (sw. row 3) to playfield switches
J209 - 4 White-Yellow (sw. row 4) to playfield switches
J209 - 5 White-Green (sw. row 5) to playfield switches
J209 - 6
N/C
J209 - 7 White-Blue (sw. row 6) to playfield switches
J209 - 8 White-Violet (sw. row 7) to playfield switches
J209 - 9 White-Gray (sw. row 8) to playfield switches
J210 - 1 Black (Grd) from Power Driver Brd J114-5,7
J210 - 2 N/C
J210 - 3 Black (Grd) from Power Driver Brd J114-5,7
J210 - 4 Gray (+5V) from Power Driver Brd J114-3,4
J210 - 5 Gray (+5V) from Power Driver Brd J114-3,4
J210 - 6 Gray-Green (+12V) from Power Driver Brd J114-1,2
J210 -7 Gray-Green (+12V) from Power Driver Brd J114-1,2
J211, 34-pln Ribbon Cable (data) To/from J113
J212 -1 Green-Brown (sw. col. 1) to COinDoor Brd J1-1
J212 - 2 Green-Red (sw. col. 2) to Coin Door J1-7
J212 - 3 N/C
J212 - 4 White-Brown (sw. row 1) to Coin Door Brd J1-6
J212 - 5 N/C
J212 - 6 White-Red (sw. row 2) to Coin Door Brd J1-5
J212 -7 White-Orange (sw. row 3) Coin Door Brd J1-4
J212 - 8 White-Yellow (sw. row 4) to Coin Door Brd J1-3
WHITE WATER 3-33
