A-15765
8-lamp Board Assembly
&
Schematic
NOTE: Use #194 Bulbs ONLY.
L4
L5
r-I [J-[J-[J-[J-[J-[J [J-[J-[J-'I
1
J1
11
L1
L2
L3
L6
L7
La
J1
( 1 "\_
(
2 ../
CI)--KeY---
CI)------G)
c=D------G)
c=D------G)
CL)-----(V
c=D------G)
c=D------G)
GD----(?)
( 11
a
Left Side
J1 - 1 Red from Chase Lamp Board J2-11
J1 - 2 Red from Chase Lamp Board J2-10
J1 -
3 N/$
J1 - 4 Blue-Yellow from Chase Lamp Board J2-8
J1 - 5 Blue-Orange from Chase Lamp Board J2-1
J1 - 6 Blue-Red from Chase Lamp Board J2-3
J1 - 7 Blue-Brown from Chase Lamp Board J2-5
J1 -
a
Blue-Green from Chase Lamp Board J2-7
J1 - 9 Blue-Gray from Chase Lamp Board J2-4
J1 - 10 Blue-Violet from Chase Lamp Board J2-2
J1 - 11 Blue-Black from Chase Lamp Board J2-6
Right Side
J1 - 1 Red from Chase Lamp Board J3-2
J1 - 2 Red from Chase Lamp Board J3-1
J1 -
3
N/C
J1 - 4 Black-Yellow from Chase Lamp Board J3-7
J1 - 5 Black-Orange from Chase Lamp Board J3-4
J1 - 6 Black-Red from Chase Lamp Board J3-9
J1 - 7 Black-Brown from Chase Lamp Board J3-11
J1 -
a
Black-Green from Chase Lamp Board J3-6
J1 - 9 Black-Gray from Chase Lamp Board J3-10
J1 -10 Black-Violet from Chase Lamp Board J3-8
J1 - 11 Black-Blue from Chase Lamp Board J3-5
WHITE WATER 3-22
