Playfield Parts
Item
Part
No.
1 02-4003
a) 23-6300
2 12-6842
3 B-13269
4 C-11626-L-3
a) 20-9250-6
5 A-13274-L
6 01-9521
7 12-6466-10
8 B-12665
a) B-11203-R-1
9 B-13280
a) B-13276
10 C-13318
11 B-13319
12 R-13190
13 B-13349
a) B-,3225
14 B-13377
15 B-12583-6
16 B-13350
17 A-8244-L
18 C-11223-1
a) C-13205-1
~9 B-9414-2
a) B-9415-1
20 0-13384
21 C-13335
22 A-12506
a) 12-6824
23 C-13334
24 A-13376
a) 12-6505
b) 12-6785
25 B-13333
26 B-9414-3
a) B-9415-1
Description
Post
Rubber
Bottom Arch Fence
Left LOCK Kickback
Lwr Left Flipper Assembly
Lg Flipper Paddle
&
Shaft
Left Flipper Return Frame
Ball Guide
Wireform
Kicker Arm (WSlingW)Assembly
Coil
&
Bracket Assembly
Diverter Arm
&
Shaft Assembly
Diverter Actuator Assembly
Ball Guide Assembly
Ball Guide Assembly
Right Ramp Assembly
Left Cellar Loop
Cellar Kickback Assembly
Cellar Sign Bridge Assembly
Oblong YellowStandup Target
Right Cellar Loop
&
Runway
One-way Ball Gate
3-Bank Drop Target
3-Bank Opto Board
YellowJet Bumper
Bumper CoillBracket Assembly
Ball Guide Assembly
Ball Guide Assembly
Ball Gate Assembly
Gate Wire
Ball Guide Assembly
Ball Gate Assembly
Gate Wire
Switch Actuating Wire
Ball Guide Assembly
Red Jet Bumper
Bumper CoillBracket Assembly
Item Part
No.
Description
27 C-13312-1 1-Bank Drop Target
a) C-13311 1-BankOpto Board
28 C-13332 Ball Guide Assembly
29 01-9522 Eject Hole Ball Deflector
30 B-9361-R Top Right Eject Hole
a) B-9362-L-1 Coil
&
Bracket Assembly
b) 03-7351-1-9 Tr Red Plastic Ball Seat
31 B-13351 R Ramp L Entry Ball Guide
32 B-13399 R Ramp R Entry Ball Guide
33 B-13320 Ball Guide Assembly
34 B-11696-5 Mdl (Round White)Standup Target
35 A-13359 Ball Guide Assembly
36 B-13233 Lifting Ramp Assembly
37 B-13339 Spinner Assembly
a) 12-6780 Switch Actuator Wire
38 R13129
Left Ramp Assembly
39 B-12583-4 R Ramp (Oblong Red) StandupTarget
40 C-11626-R-3 Upper Right Flipper Assembly
a) 20-9250-6 Flipper Arm on Shaft
41 A-13385 Ball Guide Assembly
42 0-13383 Ball Guide Assembly
43 A-8244-R One-way Ball Gate
44 B-11696-15 R (RoundOrange) Standup Target
45 0-13191 Wire Chute Assembly
46 C-13317 Ball Guide Assembly
47 A-13274-R Right Flipper Return Frame
48 C-11626-R-3 Lower Right Flipper Assembly
a) 20-9250-6 Flipper Arm on Shaft
49 A-13360 Ball Guide Assembly
50 Parts below are located beneath Bottom Arch:
a) B-8623
Upper Trough Baffle Assembly
b) C-8235
Lower Trough Baffle Assembly
c) 12-6542 Baffle Wire
d) 01-3569-1 Ball Trough (runway)
e) 01-5575 Bottom Arch Mounting Bracket
f) B-8039-2 Outhole Kicker Assembly
