Wheels Drive Assembly
Wheels Drive Assembly
:p~n 0-13199
Item Part Number
Description
Item Part Number
Description
1 01-9406
Bracket Mounting
12 20-9610
Bearing - Flange
2 02-4418
Shaft
13 20-9639
Metric MS Screw
3 02-4419
Adjusting Screw
14 31-1536-574-1
Decal - Large
4 03-8343
Pinion
15 31-1536-574-2
Decal - Medium
5 03-8344
Gear,72T
16 31-1536-574-3
Decal- Small
6 03-8345
Gear,84T
17 4006-01076-04
Set Screw, 6-32 x 1/4
7 03-8346
Gear, 115T
18 4008-01017-08
Mach. Screw, 8-32 x
1/2
8 03-8347
Gland
19 4008-01 041-08 Mach. Screw, 8-32 x
1/2
9 03-8363
Nut-LOCking
20 4108-01004-06
Sh. Metal Screw,
#8x3/8
10 14-7955
Motor
21 4700-00016-00
Flatwasher,
11 16-8587 -1000 Label-Adjustment Motor
3/16
x
7/16
x 17ga.
Playfield Ramp Assemblies
Left Ramp Assembly
Right Ramp Assembly
pin
R-13129
pin
R-13190
Item Part Number
Description
Item Part Number
Description
1 A-12506
Switch Gate Assembly
1 B-13233
Lifting Ramp Assy
2 A-7438-1
Terminal Strip Assembly
2 B-13300
Switch
&
Bracket Assy
3 01-8641
Bracket - Switch
3 01-9499
Plate - Bearing
4 01-8774
Bracket - Switch
4 03-8171-9
TIL
Dome Tr- Red
5 01-9387
Ramp Flap
5 03-8172-13
TIL
Dome Tr- Red
6 03-8335
Rear Ralll>
6 03-8342
Ramp - Left
7 5647-12073-11 (.lSwitch
7 03-8369
Cover - Switch
8 5647-12133-04 (.lSwitch
8 24-8802
Bulb #906 (13V, .69A)
9 24-8812
Socket - Light
