Eject Hole Arm Assembly
Associated Parts
B-9362-L-1
B-7572-1
01-8-508-S
4006-01017-06
4406-01119-00
AE-23-800
03-7066
Coil & Bracket Assembly
Bracket & Stop Assembly
Coil Retaining Bracket
Mach. Screw, 6-32 x 3/8
Nut, 6-32 ESN
Coil Assembly
Coil Tubing
TR Eject Hole Arm Assembly
pin
B-9361 -R
Item
1
2
3
4
5
a)
b)
c)
6
7
8
9
Part Number
12-6227
A-7471-R
10-362
A-6949-R
A-8050-1
02-3407
20-8716-5
03-8085
12-6227
4700-00030-00
4700-00103-00
A-8268
Description
Hair Pin Clip
Eject Cam Assembly
Eject-Spring (Plain)
Spring Plate Assembly
Plunger Assembly
Coil Plunger
Roll Pin
Armature Link
Hair Pin Clip
Flatwasher,
17/64
x
112
x 15ga.
Flatwasher, 17/64 x
112
x 28ga.
Mounting Bracket Assy
Bottom Arch Kickback Assembly
II II
II II
1L._j1
I~-ll
II
-4f----{
2
o
Bottom Arch Kickback Assembly
pin
8-13269
Item Part Number
1 A-13270
2 AE-23-800
3 B-7409-2
4 01-8-508-T
5 03-7067
6 10-135
7 23-6420
8 4008-01017 -05
Description
Bell Armature Assembly
Coil Sub-Assembly
Mtg. Bracket Assembly
Coil Retaining Bracket
Coil Tubing
Solenoid Spring
Rubber Grommet
Mach. Screw, 8/32 x 5/16
