Flipper Assembly
Lower & Upper Right Flipper Assembly
C-11626-R-3
Item Pan Number
Description
Item Pan Number
Description
1 HW-30018-6
Wire, 18 AWG, Blue
g) B-10657-R
Flipper Crank Assy, R.
2 03-7520-2
Ty-Wrap, Nylon
1.) 01-8073-R
Flipper Crank, R.
3 20-6516
Speednut, Tinnerman
2.) 17-1037
Crank Washer
4 5045-12098-00
Capacitor, 2.2 IlFd, 250V, 20% 3.) 4010-01066-18 Cap
Screw,10-32x1-1/8
5 RM-21-06
Sleeve, Vinyl (Cap. leads)
4.) 4410-01127-00 Nut, 10-32 Hex Hd.
6 4010-01066-06
Cap Screw, 10-32 x
3/8,
SH
5.) 4700-00107-00 Washer,
5/80.d.x13/64
7 4701-00004-00
Lockwasher, #10 Split
l.d, x 12ga.
8 A-12111
Flipper Stop Assembly
6.) 4701-00004-00 Lockwasher, #10 Split
9 FL-11630
Flipper Coil (Red)
7.) RM-23-06
Tubing, H. S.
1/4
DWP
10 4006-01017-04
Mach. Screw, 6-32 x
1/4
14 23-6577
Bumper Plug
11 01-7695
Solenoid Bracket
15 03-7568
Flipper Bushing
12 10-376
Coil Plunger Spring
16 4006-01005-06 Mach. Screw, 6-32 x
3/8
13 B-10655-R
Crank Link Assembly, Right
17 4406-01117-00 Nut, 6-32 Hex.
a) 02-4179
Link Spacer Bushing
18 C-11627-R
Flipper Base Assy, R.
b) 4010-01086-14
Cap Screw, 10-32 x
7/8,
SH 19 06-14G
Insulating Blade
c) 4700-00023-00
Washer,
5/8 x13/64
x16ga.
20 4105-01019-10 Sh. Metal Screw,
d)
4701-00004-00
Lockwasher, #10 Split
#5 x
5/8
e) 4410-01132-00
Nut, 10-32 ESNA
21 4701-00002-00 Lockwasher, #6 Split
f)
A-10656**
Flipper Link Assembly
22 23-6622
Tape, Double-sided
1.) 02-4219
Coil Plunger
23 03-7811
End of Stroke (EOS) Sw
2.) 20-9370-1
Spring Pin,
5/32
dia. x
7/16
3.) 03-8050-1
Flipper Link
•• Also See Separate Diagram
.....................................................................................
.
Associated Pans:
20-9250-6
23-6519-4
Flipper Arm on Shaft
Red Rubber Ring
