Triac Driver Assembly
~
o
c....
•
....L
T"""
~~-
o ~
a:
0
0
01
•
0
§
C")
0
J
0
0
•
c....
0
I\.)
0
R4
0
0
r-,
I
I
I
I
F10
Triac Driver Assembly
pin
C-13088
Item Part Number
Ckt Designator
Description
1 5768-12520-00
Triac Driver PCB
2 5791-10862 -04
J1
Connector, 4-pin Hdr, Sq Pin
3 5791-10862-05
J2
Connector, 5-pin Hdr, Sq Pin
4 5791-10862-07
J3
Connector, 7-pin Hdr, Sq Pin
5 5733-12060-01
Fuse Holder (F1)
6 5731-09651-00
F1
Fuse,1A,S-B,250v
7 5131-12543-00
Q1
TriacISL,400V,10A.
8 5705-12464-00
Heatsink
9 5012-12530-00
R1
Resistor, 6800, 5w, 10%
10 5010-08930-00
R2
Resistor, 4700,
1/2w, 5%
11 5010-09441-00
R3
Resistor, 1000,
1/2w, 5%
12 5010-09789-00
R4
Resistor, 390,
1/2w, 5%
13 5045-09795-00
C1
Capacitor, .01utd, 400V (±10%)
Metalized Poly
14 5040-09537 -00
C2
Capacitor, 1001ltd, 100V (±20%)
15 5070-09054-00
D1
Diode, 1N4004, 1.0A.
16 5490-09805-00
U1
IC, 3030 Triac Driver
17 4004-01005-06
Mach. Screw, 4-40 x
3/8
18 4404-01117-00
,
Nut, 4-40 Hex.
-
19 4703-00015-00
Lockwasher, #4 External
