A-17051-1
Coin Door Interface PCB Assembly
o
0 0·* 0 0 0
a
0
a a
0
o a
0
a
0
a
0 0
a a
0
a
0
Part Number
5791-10862-03
5791-10862-05
5791-10862-11
5791-10862-12
5791-10862-13
5791-10862-15
5791-11000-10
5645-09025-00
5070-09054-00
Designator
J8
J2,J9
J1, J7
J3
J5
J6
J4
SW5
01 - 011
Description
Connector, 3-pin Header Str. Sq.
Connector, 5-pin Header Str. Sq.
Connector, 11-pin Header Str. Sq.
Connector, 12-pin Header Str. Sq.
Connector, 13-pin Header Str. Sq.
Connector, 15-pin Header Str. Sq.
Connector, 10-pin Header Str. Sq.
Switch DIP 8 Pos.
Diode, 1N4004, 1.0A.
A-17316
Flipper Opto PCB Assembly
OPTQ
o
()
Part Number
A-20207
5010-09061 -00
5490-14575-00
5791-13830-07
03-9001
OPT02
Designator
R1, R2
OPT01,
OPT02
J1
o
()
J
1
(\
\_)
Description
Flipper Opto Switch PCB
Resistor, 680£2, 1/2w, 5%
IC Opto Integ Schmitt 10mA.
Connector, 7-pin Header Solid Sq.
Interrupter Flip-Opto
2-10
