DIP SWITCH SETTINGS
AND JUMPERS
1MEG, 2MEG, 4 MEG EPROM
EPROM Jumper Settings for
US
Dip Switch Chart
Country
SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
America
Off Off On On On On On On
Euopean
Off Off On On On Off On On
French
Off Off On On On On Off Off
German
Off Off On On On On On Off
Spain
Off Off On On Off On On On
SOLENOID/FLASHER TABLE
Sol.
Function
Solenoid
Voltage Connections
Drive
Drive Connections
Drive
Solenoid Part number
No.
Type
Xister
Wire
Flashlamp Type
Playfleld Backbox Cabinet
Playfleld Backbox Cabinet
Color
Playfleld
Backbox
01 Trough
High Power
J107-2
082 J130-1
Vio-Bm AE-26-1500
--
02 Plunger
High Power
J107-2
080 J130-2
Vio-Red
AE-23-800
---
03 Left Lock Up
High Power
J107-2
078 J130-4
Vic-Org AE-27-1200
---
04 Right Back Popper
High Power
J107-2
076 J130-5
Vic-Yel
AE-24-900
---
OS
Ramp Down
High Power
J107-2
064 J130-6
Vic-Gm AE-26-1200
---
06 Not Used
High Power
066
Vic-Blu
-
--
07 Knocker
High Power
J107-2
068
J130-8
Vic-Blk
--
AE-23-800
08 Right Front Popper
High Power
J107-2
070 J130-9
Vic-Gry
AE-23-800
---
09 Left Sling
Low Power
J107-3
058 J127-1
Bm-Blk
AE-26-1200
--
10 Right Sling
Low Power
J107-3
056~
Brn-Red AE-26-1200
---
11 Left Jet
Low Power
J107-3
054
Brn-Org AE-26-1200
--
12 Bottom Jet
Low Power
J107-3
052
Bm-Yel
AE-26-1200
---
13 Right Jet
Low Power
J107-3
050 J127-6
Brn-Gm AE-26-1500
--
14 Phone Flasher
Low Power
J107-6
048 J127-7
Bm-Blu
#906 (1)
--
15 Not Used
Low Power
046
Bm-Vio
--
---
16 Ramp Up
Low Power
J107-3
044 J127-9
Brn-Gry SM1-28-900-DC
---
17 Back Flasher
Flasher
J107-6 J105-5
042 J126-1 J125-1
Blk-Bm #906 (2)
#906 (1)
18 lAutofire Flasher
Flasher
J107-6
040 J126-2
Blk-Red
#89 (1)
-
19 Lower Left Flasher
Flasher
J107-6 J105-5
038 J126-3 J125-3
Blk-Org
#906 (1)
#906 (1)
20 Spinner Flasher
Flasher
J107-6 J105-5
tit
J126-4
J125-5
Blk-Yel
#906 (1)
#906 (2)
21 Lower Right Flasher
Flasher
J107-6 J105-5
J126-5 J125-6
Blu-Grn
#906 (1)
#906 (1)
22 Motor 3-Bank
Flasher
J116-2
J126-6
Blu-Blk
14-802612V
--
23 Left Slot B
Flasher
J116-2
034 J126-7
Blu-Vio 14-802412V
-
24 Left SlotA
Flasher
J116-2
032 J126-8
Blu-Gry
14-802412V
---
25 Center Slot B
Gen. Purpose J116-2
026 J122-1
Blu-Bm 14-802412V
--
26 Center Slot A
Gen. Purpose J116-2
024 J122-2
Blu-Red 14-802412V
---
27 Right Slot B
Gen. Purpose J116-2
022 J122-3
Blu-Org 14-802412V
---
28 Right SlotA
Gen. Purpose J116-2
020 J122-4
Blu-Yel
14-802412V
---
36 Up Down Post
Low Power
J907-8,9
05 J902-1
Org-Gry AE-27-1200
---
General illumination
01 Left Playfield
G.!.
J121-1
018 J121-7
rv'Jht-Brn
#44
---
02 Right Playfield
G.I.
J121-2
010 J121-8
rv'Jht-Org
#44
---
03 Back Playfield
G.!.
J121-3
014 J121-9
rv'Jht-Yel
#44
---
04 Insert 1
G.!.
J120-5
016
J120-10
rv"Jht-Grn
--
#555
05 Insert 2
G.!.
J120-6
012
J120-11
rv"Jht-Vio
-
#555
Flipper Circuits
Voltage
Drive
Drive
Drive Wire
Coli
Coil
Connections
Transistors
Connectors
Colors
Part No.
Color
Playfield
Power
Hold
Playfield
Power
Hold
29
.
Lwr. Rt. Power J907-1 (Red-Grn)
04
J902-13
Yel-Grn
30 Lower Right Flipper
Lwr. Rt. Hold J907-1 (Red-Grn)
011
J902-11
Org-Grn
FL-15411
ORANGE
31
Lwr. Lt. Power
J907-4 (Red-Blu)
03
J902-9
Yel-Blu
32 Lower Left Flipper
Lwr. Lt. Hold J907-4 (Red-Blu)
09
J902-7
Org-Blu
FL-15411
ORANGE
33
Upr. Rt. Power J907-6 (Red-Vio)
02
J902-6
Yel-Vio
34 Upper Right Flipper
Upr. Rt. Hold J907-6 (Red-Vio)
07
J902-4
Org-Vio
NOT USED NOT USED
35
Upr. Lt. Power J907-8 (Red-Gry)
01
J902-3
Yel-Gry
36 Upper Left Flipper
uor, Lt. Hold J907 -8 (Red-Gry)
05
J902-1
Org-Gry
SEE
ABOVE
-
J1xx Power Driver Board, J9xx Fhptronlc II Board, 24-6549=#44 bulb, 24-8704-#89 bulb, 24-8768-#555 bulb, 24-8802-#906 bulb
