Coin Door Interface
p.e.B.
Assembly
A-17051-1
J1-1 Orange-Gray dedicated row 8 from J205-9
J1-2 Orange-Violet dedicated row 7 from J205-8
J1-3 Orange-Blue dedicated row 6 from J205-7
J 1-4 Orange-Green dedicated row 5 from J205-6
J1-5 Orange-Yellow dedicated row 4 from J205-4
J1-6 Orange-Black dedicated row 3 from J205-3
J1-7 Orange-Red dedicated row 2 from J205-2
J1-8 Orange-Brown dedicated row 1 from J205-1
J1-9 Key
J1-10 Black ground from J205-10
J1-11 Orange-White switch enable from J205-12
J2-1 Black ground from J116-3
J2-2 Gray-Yellow +12VAC from J116-2
J2-3 White-Violet G.!. 6.8VAC from J119-1
J2-4 Key
J2-5 Violet G.!. from J119-3
J3-1 Green-Brown switch column 1 from J212-1
J3-2 Green-Red switch column 2 from J212-2
J3-3 White-Brown switch row 1 from J212-4
J3-4 White-Red switch row 2 from J212-6
J3-5 White-Orange switch row 3 from J212-7
J3-6 White-Yellow switch row 4 from J212-8
J3-7 Key
J3-8 Yellow-Gray lamp column 8 from J136-3
J3-9 Red-Blue lamp row 6 from J134-7
J3-10 Red-Violet lamp row 7 from J134-8
J3-11 Red-Gray lamp row 8 from J134-9
J3-12 Not Used
J4 Not Used
J5-1 Violet G.!. return to coin door
J5-2 White-Violet G.!. 6.8VAC to coin door
J5-3 Black ground to coin door
J5-4 Orange-Brown dedicated switch row 1 to coin door
J5-5 Orange-Red dedicated switch row 2 to coin door
J5-6 Orange-Black dedicated switch row 3 to coin door
J5-7 Orange-Green dedicated switch row 5 to coin door
J5-8 Orange-Blue dedicated switch row 6 to coin door
J5-9 Orange-Violet dedicated switch row 7 to coin door
J5-10 Key
J5-11 Orange-Gray dedicated switch row 8 to coin door
J5-12 Green-Red switch column 2 to coin door Slam Tilt
J5-13 White-Brown switch row 1 to coin door Slam Tilt
J6 Not Used
J7-1 Yellow-Gray lamp column 8 to cabinet
J7-2 Red-Blue lamp row 6 to cabinet
J7-3 Red-Violet lamp row 7 to cabinet
J7-4 Red-Gray lamp row 8 to cabinet
J7-5 Key
J7-6 Green-Brown switch column 1 to cabinet
J7-7 Green-Red switch column 2 to cabinet
J7-8 White-Orange switch row 3 to cabinet
J7 -9 Not Used
J7-10 White-Brown switch row 1 to cabinet
J7-11 White-Orange switch row 3 to cabinet
J8-1 White switch row to cabinet Slam Tilt
J8-2 Key
J8-3 Green switch column to cabinet Slam Tilt
J9-1 White-Yellow switch row 4 to Plumb Bob Tilt
J9-2 Key
J9-3 Green-Brown switch column 1 to Plumb Bob Tilt
J9-4 White-Red switch row 2 to Interlock Switch
.J9-5 Green-Red switch column 2 to Interlock Switch
3-31
