WPC Security CPU Board
A-17651-50044
J201 Ribbon Cable data to J602
J202 Ribbon Cable data to J903; J506; J601
J203 Not Used
J204 Ribbon Cable data to A-16100 J1
J205-1 Orange-Brown Dir Sw 1, Left Coin to J 1-14
J205-2 Orange-Red Dir Sw 2, Center Coin to J1-13
J205-3 Orange-Black Dir Sw 3, Right Coin to J1-12
J205-4 Orange-Yellow Dir Sw 4, 4th Coin to J1-17
J205-5 Key
J205-6 Orange-Green Dir Sw 5, Escape/Service to J1-11
J205-7 Orange-Blue Dir Sw 6, DownNol
Down to J1-10
J205-8 Orange-Violet Dir Sw 7,
UpNol
Up to J1-9
J205-9 Orange-Gray Dir Sw 8, Enter/Test to J1-S
J205-10 Black ground to J 1-15
J205-11 Not Used
J205-12 Orange-White Enable to J1-1S
J206 Not Used
J207-1 Green-Brown Sw Coli
to playfield switches
J207-2 Green-Red Sw Col 2 to playfield switches
J207-3 Green-,Orange Sw Col 3 to playfield switches
J207-4 Green-Yellow Sw Col 4 to playfield switches
J207-5 Green-Black Sw Col 5 to playfield switches
J207-6 Green-Blue Sw Col6 to playfield switches
J207-7 Green-Violet Sw Col 7 to playfield switches
J207-S Key
J207 -9 Not Used
J207-10 Not Used
J207 -11 Not Used
J20S Not Used
J209-1 White-Brown Sw Row 1 to playfield switches
J209-2 White-Red Sw Row 2 to playfield switches
J209-3 White-Orange Sw Row 3 to playfield switches
J209-4 White-Yellow Sw Row 4 to playfield switches
J209-5 White-Green Sw Row 5 to playfield switches
J209-6 Key
J209-7 White-Blue Sw Row 6 to playfield switches
J209-S White-Violet Sw Row 7 to playfield switches
J209-9 White-Gray Sw Row S to playfield switches
J210-1 Black ground from J904-4;J3-4 Sound Bd; J114-7
J210-2 Key
J210-3 Black ground from J904-4; J3-5 Sound Bd; J114-5
J210-4 Gray +5VDC from J901-1; J3-1 Sound Bd; J114-4
J210-5 Gray +5VDC from J3-3 Sound Bd; J114-3
J210-6 Gray-Green +12VDC from J904-2; J114-2
J210-7 Gray-Green +12VDC from J114-1
J211 Ribbon Cable data from J 113
J212-1 Green-Brown Sw Col1 to J1-1
J212-2 Green-Red Sw Col2 to J1-7
J212-3 Not Used
J212-4 White-Brown Sw Row 1 to J1-6
J212-5 Key
J212-6 White-Red Sw Row 2 to J1-5
J212-7 White-Orange Sw Row 3 to
J1-4
J212-S White-Yellow Sw Row 4 to J1-3
J213-1 Black to battery holder J1-1
J213-2 Black to battery holder J1-2
J213-3 Key
J213-4 Gray to battery holder J 1-4
J213-5 Gray to battery holder J1-5
3-28
