Flipper Opto p.e.B. Assembly
A-17316
Left Side Flipper Cabinet Opto Switch Board
J1-1
Black-Blue from Fliptronic II Board
J905-5
J
1-2 Blue-Gray from Fliptronic II Board J905-2
J1-3 Not Used
J1-4 Orange from Fliptronic II Board J905-6
J1-5 Key
J1-6 Gray-Yellow to Right Flipper Opto Board J1-6
J
1-7 Gray-Yellow from Fliptronic II Board
J
118-2
Right Side Flipper Cabinet Opto Switch Board
J2-1 Black-Yellow from Fliptronic II Board J905-3
J2-2 Blue-Violet from Fliptronic II Board J905-1
J2-3 Orange from Fliptronic II Board J905-6
J2-4 Orange from Left Flipper Opto Board J1-4
J2-5 Key
J2-6 Gray-Yellow to Left Flipper Opto Board J1-6
J2-7 Not Used
3-12
