Item Coili
Assy.
No. Flasher No. Number.
21 24-8802 A-20523
22 14-8026 A-20483
23 14-8024 A-20425
24 14-8024 A-20425
25 14-8024 A-20425
26 14-8024 A-20425
27 14-8024 A-20425
28 14-8024 A-20425
36 AE-27 -1200 A-17932
Solenoid/Flasher Locations
(continued)
Description
General Illumination Circuits
Item No. Description
Bulb No.
01 Left Playfield
#44
02 Right Playfield
#44
03 Back Playfield
#44
04 Insert 1
#555
05 Insert 2
#555
G.I. String 1
G.I. String 2
G.I. String 3
G.I. String 4
G.I. String 5
Lwr R Flasher (1)
Motor 3-Bank
Left Slot B
Left Slot A
Center Slot B
Center Slot A
Right Slot B
Right Slot A
Up Down Post
Flipper Coils
Item No.
Coil No.
29 & 30 FL-15411
31 & 32 FL-15411
Color Assy. No.
Description
Org A-14876-R-5 Lwr R Flipper
Org A-15849-L-4 Lwr L Flipper
24-6549 = #44 bulb
24-8704
=
#89 bulb
24-8768
=
#555 bulb
24-8802
=
#906 bulb
2-47
