Lower Playfield Parts
@
Item Part Number
Description
1 01-9211
Playfield Hanger Bracket Assy.
2 A-20439
Shooter Lane Auto Kicker Assy.
3 01-11781
Support Bracket Assembly (2)
4 A-20425
Reel Assembly
5 A-20529
7-Lamp PCB Assembly
6 A-20419
Plastic Trough Assembly
7 A-20231
Lift Ramp Assembly
@
8 A-17749.1-2
Slide Playfield Assembly, Right
9 A-19543
Ball Popper Assembly
10 A-9415-2
Jet Bumper Coil Assembly
11 A-17749.1-1
Slide Playfield Assembly, Left
12 A-20491
Trough Assembly
13 A-20483
Motor Bracket Assembly
14 A-20512
3-Position Moving Target Assy.
15 A-20487
Bottom Trough Assembly
16 A-20527
t t-Larnp PCB Assembly
17 A-17932
Disappearing Post Assembly
18 A-20435
Eject Assembly
19 A-20530
19-Lamp PCB Assembly
20 A-17223
16-0pto PCB w/Bracket Assy.
21 A-15849-L -4 Flipper Assembly Complete
22 A-14876-R-5
Flipper Assembly Complete
23 A-19963-1
Ball Trough Assembly
w/Cables
24 A-17811
Kicker Arm Assembly
a)
A-9362-R-3
Coil & Bracket Assembly
25 A-17811
Kicker Arm Assembly
a)
B-9362-L-2
Coil & Bracket Assembly
26 A-20488
Ball Popper Assembly
27 A-20163
5-Lamp PCB Assembly
28 A-15340
Motor EMI w/Brake PCB Assy.
Underside of Playfield, Viewed in Raised Position
2-40
