Upper Playfield Parts
Item Part Number Description
Item Part Number
Description
No.
No.
1 01-9211
**Playfield Hanger Bracket
45 01-14064
*Ramp Support Bracket
2 01-13638
Bottom Arch Ball Guide
46 A-20531-4
Playfield Plastic Assembly
3 A-16998.1
*Opto P.C.B.
47 A-20557
Ball Popper Ball Guide Assembly
4 A-15849-L -4 Flipper Assembly Complete
49 02-5217
Lift Ramp Pin
20-10110-5
Flipper Bat w/Shaft, White
12-6227
Hair Pin Clip (2)
5 03-9216-12
Flipper Return Guide (2)
50 01-14044
Ball Guide
6 A-17813
Rollover Switch Assembly
51 A-20231
Lift Ramp Coil & Bracket
7 A-17801
Kicker Count Switch Assembly
12-6227
Hair Pin Clip
8 A-17811
Slingshot Kicker Assembly
52 A-20494
Lift Ramp Assembly
B-9362·L-2
Coil & Bracket Assembly
53 A-20493
Spin Target Assembly
10-128
Kicker Spring
54 A-16817-7
Oblong Standup Target, Black
9 02-5049-8
Post 1.38"
55 02-4765-2
Post 2.75"
10 02-5107
Adjusting Post
56 01-14040
Ball Guide
11 01-14036
Ball Guide
57 A-20505-6
Dual Target Assembly, Yellow
A-17985-L
Eject Switch Assembly
58 A-20425
Reel Assembly
A-20435
Eject Assembly
59 A-17838
Stud Plate
14 A-17799-15
Round Standup Target, Red
02-5049-6
Spacer 1.62"
15 04-10262.1
Ball Guide
60 A-20421
Right Ramp Assembly
16 A-20531-1
Playfield Plastic Assembly
61 A-20488
Ball Popper Assembly
18 02-4250-23
Spacer 1
7/16"
A-20523
Hood & Light Assembly
19 A-20659
Reflector/Light & Cable Assembly
62 A-20431
Ball Gate Assembly
20 A-20521
Ball Gate Assembly, Left
63 12-7305
Ball Guide Wireform
21 04-10283
Decal & Window Assembly
64 A-17811
Slingshot Coil & Bracket
22 01-14053
Nut Plate
B-9362-R-3
Coil & Bracket Assembly
23 A-20575-5
Round Standup Target, White (4)
10-128
Kicker Spring
24 A-20426
Center Ramp Assembly
65 01-14034
Ball Guide
25 A-20483
*Motor & Bracket Assembly
66 A-15802-P
"Level
26 A-15340
'Motor EMI wlBrake Assembly
67 A-14876-R-5
Flipper Assembly Complete
27 A-20512
Moving Target Assembly
20-10110-5
Flipper Bat w/Shaft, White
02-4259
Roller
68 A-19963-1
Trough Assembly
28 A-18530-4
Oblong Standup Target, Red
69 A-20439
"Shooter Lane Auto-Kicker Assy
29 A-20531-3
Playfield Plastic Assembly
70 01-14117
"Back Panel Bracket
30 02-10267
Ball Guide
71 01-14237
'Ball Deflector Bracket
31 02-10263
Ball Guide
32 02-10264
Ball Guide
NOT SHOWN:
33 01-14039
Ball Guide
A-13204-50044 Bottom Arch Assembly
34 A-17838
Stud Plate
A-17812-2
Cable Mounting Bracket
W'
02-5049-9
Post 2.56"
A-17812-4
Cable Mounting Bracket 1"
35 01-14087
Ball Deflector
A-20419
Under Playfield Trough Assy
36 A-20574
"Telephone Assembly
A-20487
Bottom Trough Assembly
37 02-4765-21
Post 3.88"
A-20491
Trough Assembly
38 A-20420
Main Ramp Assembly
A-20660
Playfield Plastic Assembly
39 A-17932
Disappearing Post Assembly
03-9459-1
Jet Bumper Area Mylar
40 A-20522
Back Panel Assembly
03-9459-2
Full Playfield Mylar
41 02-5049-10
Spacer 2.75"
03-9459-3
Ramp Drop Area Mylar
42 A-20531-2
"Roulette Plastic Assembly
03-9459-4
Ramp Drop Area Mylar
43 A-19543
Ball Popper Assembly
36-50044
tScreened Playfield
04-10241.2
Top Hood Assembly
44 A-9415-2
Jet Bumper Coil Assembly
A-12753-2
Lug & Diode Assembly
MISCELLANEOUS:
B-9414-3
Jet Bumper Assembly, Red
*Located under playfield.
B-12030-2
Jet Bumper Leaf Switch Assy
** Not Shown
03-8254-9
Jet Bumper Cap, Red
+The WHO DUNNIT hardcoat playfield does not require
23-6710-1
Clear Tubing
a full mylar. However, mylars can be purchased
through your local Bally Distributor.
2-38
