Reel Assembly
Item Part Number Description
Item Part Number
Description
1 01-14075
Reels Mounting Frame
11 4004-01003-04 Mach. Screw, 4-40 x
1/4" (12)
2 01-14076
Motor Mounting Bracket (3)
12 4006-01003-04 Mach. Screw, 6-32 x
1/4" (6)
3 03-9410.1
Reel (3)
13 4006-01003-14 Mach. Screw, 6-32 x
7/8" (12)
4 14-8024
Stepper Motor, 1.8 (3)
14 4006-01076-04 Set Screw, 6-32 x
1/4" (3)
5 A-20507
Socket & Bulb w/Diode (3)
15 4008-01 003-04 Mach. Screw, 8-32 x
1/4" (14)
6 A-19745-1
Stepper Motor PCB wlSpacers (3)
16 4006-01003-03 Mach. Screw, 8-32 x
3/16" (3)
*7 31-2517-3A Decal, Left
17 A-20511
Reel Opto PCB Assembly (3)
*8 31-2517-1A Decal, Center
18 03-7655-8
Wire Harness Clip,
1/2"
*9 31-2517-2A Decal, Right
**19 H-20567
Cable
10 03-9454
Tie-Wrap - Nylon
3-7/8" (10)
20 03-7655-4
Wire Harness Clip,
1/4" (4)
*
Not available for individual sale. Order Decal Set 31-2517.
**
Not Shown.
2-27
