A-17932
Disappearing Post Assembly
Item Part Number
Description
1 01-12441
Diverter Post Bracket
2 03-7067-5
Coil Tubing
3 01-8-508-T
Coil Retainer Bracket
4 AE-27-1200
Coil Sub-Assembly
5 10-135
Spring
6 A-17986
Bell Armature Assembly
7 23-6420
Rubber Grommet
8 4008-01 017-04 Mach. Screw, #8-32 x
1/4"
A-20435
Eject Assembly
Item Part Number
Description
1 01-14019
Eject Bracket
2 23-6420
Rubber Grommet
3 04-10207
Plunger Assembly
4 10-135
Spring
5 03-7067
Coil Tubing
6 01-8-508-T
Solenoid Bracket
7 4008-01 017 -04 Mach. Screw, 8-32 x 14
8 AE-27-1200
Coil
9 H-19523
Cable
2-23
