POWER DRIVER BOARD
A-12697-3
J101-1 Red, 9VAC from transformer secondary
J101-2 Red, 9VAC from transformer secondary
J101-3 Key
J1 01-4 Blue-White, 13VAC from transformer secondary
J1 01-5 Blue-White, loop from J1 01-4
J101-6 Blue-White, 13VAC from transformer secondary
J101-7 Blue-White, loop from J101-6
J102-1 White-Red, loop from J1 02-2
J102-2 White-Red, 16VAC from transformer secondary
J102-3 White-Red, loop from J1 02-4
J102-4 White-Red, 16VAC from transformer secondary
J102-5 Black-Yellow, loop from J1 02-6
J102-6 Black-Yellow, 16VAC from transformer secondary
J102-7 Key
J102-8 Black-Yellow, loop from J102-9
J102-9 Black-Yellow, 16VAC from transformer secondary
J103-1 Black, Ground to J2-5, A-16100
J103-2 Black, Ground to J2-4, A-16100
J103-3 Black, Ground to J2-1, A-16116
J103-4 Black, Ground to J2-2, A-16116
J104 Not Used
J10S-1 White-Blue, SOVAC to J901-1
J1 05-2 White-Blue, 50VAC to J901-3
J105-3 Key
J105-4 Not Used
J105-5 Not Used
J106 Not Used
J107-1 Not Used
. J1 07-2 Violet-Orange, SOV to playfield coils
J107-3 Violet-Yellow, SOV to playfield coils
J107-4 Key
J107-5 Red, +20V to playfield flashlamps
J 107-6 Red-White, +20V to playfield flashlamps
J108 Not Used
J109-1 Not Used
J109-2 Not Used
J109-3 Not Used
J109-4 Not Used
J109-5 Violet-Green, SOV to playfield coils
J109-6 Key
J109-7 Violet-White, 50V to playfield coils
J110 Not Used
J111 Not Used
laallill
'oooDoo.oa!
1 4 1
9
J103 J102
laa.oolllol
1
7
J101
[D'"~
rn:'
s
-
•...
,
:
...,
_
_
rn
...~
.•..
'"')
_
[II '" ...
•..
•..
_'"')
ill '"
N
•..
.•..
_'"')
J113
J114
J11S
34
1 •••••••••••••••••
1 '
~
I
33.----.2
.01l ••••••
D•• '
7
1 12·
·1
J112-1 White-Green, 9.8VAC from transformer secondary
J112-2 White-Green, loop from J112-1
J112-3 White-Green, 9.8VAC from transformer secondary
J112-.4 Key
J112-S ~'hite-Green, loop from J112-3
J113 Ribbon Cable, Data tolfrom J211
J114-1 Gray/Green, +12VDC to J210-7
J114-2 Not Used
J114-3 Gray, +SVDC to J21 0-5; JS02-3
J 114-4 Not Used
J114-5 Not Used
J114-6 Key
J114-7 Black, Ground to J210-1; J502-4; J904-4
P.C Board Legend
J1·J6 CoinDoor Inteliace Board
J1xx PowerDrtverBoard
J2XX CPUBoard
J5xx AudioBoard
J6xx Dot MatrixControllerBoard
J9XX FI.,tronlC" Board
Twilight Zone 3-32
