A-16064
Right Diverter Assembly
Item Part Number
1.
A-16063
2.
20-8790
3.
03-7066
4.
01-8413
5.
AR-2S-1500
6.
A-10821
7.
10-437
8.
A-13278
9..
A-14185
10.
A-16114
11.
4010-01082-04
12.
4010-01008-06
13.
4701-00004-00
14.
H-16611
15.
20-8712-25
Description
Right Diverter Bracket
Nylined Bearing
Coil Tubing
Coil Mounting Bracket
Coil Assembly
Flipper Stop Bracket Assembly
Kicker Spring
Plunger Assembly
Drive Arm Assembly
Diverter Assembly
Set Screw, 10-32 x 1/4"
Mach. Screw, 10-32 x 3/8 P-PH
Lockwasher, #10 Split
Cable Assembly
"E"-Ring, 1/4" Shaft
Twilight Zone 2-27
