Press the Enter button to activate the Adjustments Menu, once the menu name is shown under the
Main Menu. Press the Up or Down button to cycle through the Adjustment Menu selections. Press
the Enter button to activate the selection. Press the Up or Down button to cycle through the available
adjustments. Press the Enter button to activate an adjustment. When an adjustment is activated, the
setting value begins to flash. Use the Up or Down button to raise or lower the setting value. Press
Enter to lock in the value. If a mistake is made, press the Escape button while "Saving Adjustment
Value" is displayed. The new value is ignored and the original value is retained. Press the Enter button
to return to the Adjustments Menu. Press it again to return to the Main Menu.
A. ADJUSTMENTS MENU
A . 1 Standard Adjustments
A .2 Feature Adjustments
A . 3 Pricing Adjustments
A.4 H.S.T.D Adjustments
A .5 Printer Adjustments (optional board required)
A.1 Standard Adjustments
A.1 01 Balls Per Game
A "game" is defined by specifying the number of balls to be played.
Range:
1-10
A.1 02 Tilt Warnings
The number of total actuations of the plumb bob mechanismthat can occur before the game is
"tilted".
Range:
1-10
A.1 03 Maximum Extra Balls
The number of extra balls that a playermay accumulate.
Range:
1-10
A.1 04 Maximum Extra Balls/Ball
in Play
The number of extra balls to be awarded per ball in play.
OFF
No maximumnumberof ExtraBallsper ball in play.
1-10
1 through 10 Extra Balls per ball in play.
A.1 05 Replay System
The type of replay system to be used.
Fixed - Replay value is set and does not change during game play.
.
Auto % - Replay starting value is set and changes every 50 games to comply With the
percentage of replays desired.
A.1 06 Replay Percent·
The percentage of replays the players are able to earn when Auto Replay is used.
Range:
5-50%
A.1 07 Replay Start·
The replay start value when Auto % Replay is used. The range of this setting is 100,000,000 to
700,000,000.
Twilight Zone 1-29
