A-8039-3 Outhole Kicker Assembly
I....
I ...•....
I
I
I
1
~I
I I
4
I
Item Part Number
1.
A-6378
2.
03-7066
3.
A-6889
4.
A-8038
5.
AE-27-1200
6.
03-7176-1
7.
10-101-4
8.
20-8712-25
9.
4006-01003-03
10.
A-8335
a) 02-2364
b) 20-8716-5
c) 01-4251
Description
Mounting Plate Assembly
Coil Tubing
Kicker Lever Assembly
Coil Stop Assembly
Coil Assembly
Striker Ring
Spring-Reset
"E" Ring,
1/4"
Shaft
Mach. Screw, 6-32 x
3/16"
Coil Plunger Assembly
Coil Plunger
Roll Pin,
1/8
x 7/16"
Ball Return Link
....•......•..•.
_.'
Twilight Zone 2-22
