A-16124 Clock Assembly
Item Part Number
Description
1.
03-8833
Housing
2.
03-8834
Back Panel
3
03-8835
Face Plate
4.
03-8836
Lens
5.
03-8837
Minute Hand
6.
03-8838
Hour Hand
7.
03-8807
Cluster Gear, 48/52 -
32111
8.
03-8808
Cluster Gear,
32132 -
32/11
9.
03-8822
Cluster Gear,
32138 -32115
10.
03-8823
Cluster Gear,
32/40 -
32/12
11.
03-8824
Output Gear,
32145 -32/12
12.
A-16363
PCB Clock Assembly
13.
A-16653
Shaft & Roll Pin Assembly
14.
02-4715
Gear Shaft,
1.06"
(4 used)
15.
A-16652
Motor & Pinion Assembly
16.
02-4714
Drive Pin, 1 x 1/16"
17.
20-8712-15
"E"-Ring,
5132
dia. (8 used)
18.
20-8712-18
"E"-Ring,
3116
dia.
19.
4106-01013-28
SMS #6 x 1-3/4 P-PH (4 used)
20.
4106-01013-18
SMS #6 x 1-1/8 P-PH (4 used)
21.
Not Used
22.
4004-01005-04
Mach. Screw, 4-40 x 1/4 P-PH
23.
Not Used
24.
01-11337
Clock Mounting Bracket
25.
A-12887
Socket & Bulb Assembly
26.
4006-01003-04
Mach. Screw, 6-32 x 1/4 P-PH-SEMS
27.
03-8063-4
Light Bulb Sleeve - Red
28.
4700-00021-00
Flatwasher.
13/64
x
7116
x 21ga.
29.
03-8063-6
Light Bulb Sleeve - Yellow
'----
30.
H-16600
Clock Cable
31.
5070-09054-00
Diode, 1N4004, 1.0A.
32.
RM-21-03
Clear Tubing
*
33.
31-1751-3
Decal
34.
01-11595
Bracket, Clock Ball Trap
35.
20-9682-1
Cap, Protective
*
Not available for individual sale. Order Decal Set 31-1751.
Twilight Zone 2-32
