A-16806
Mini-Playfield Assembly
Item
part
Number
Description
1.
36-50020-1
Mini-Playfield
2.
A-16332
Street Light Assembly
3.
A-16519
Ball Guide & Switch Assembly
4.
H-16508
Flasher Cable
5.
A-16518
Ball Guide Assembly
6.
A-16416-1
Switch Bracket Assembly
7.
A-16416-2
Switch Bracket Assembly
8.
A-16416-3
Switch Bracket Assembly
9.
A-16326
Ball Guide Assembly
10.
A-12887
Socket Assembly, #555 Bulb
11.
A-12753-2
Lug & Diode Assembly
12.
A-12336-1
Socket & Bulb Assembly
13.
A-15257
Bracket & Pole Piece Assembly
14.
20-9247-1
Magnet & Pin Assembly
15.
01-11524
Mini-Playfield Protector
16.
01-11217
Ball Guide
17.
02-4425-1
Post 8-32/8-32 x
5/8"
18.
02-4660
Post Single Bumper #1 0
19.
02-4426-1
Post #8WS 6-32 Top
20.
02-4426-2
Post #8WS 6-32 Top
21.
03-8319-13
Post #8 Starred Clear
22.
03-7655-4
Cable Clamp,
1/4"
23.
03-7655-8
Cable Clamp,
1/2"
24.
03-8371
Spacer Spool #8
25.
03-8022-1
Spacer, .550 L.
"
~- -,- ,~ ~
26.
03-6047
Spacer,
9116"
27.
20-9247
Coil Magnet
28.
20-9672
Cover Switch Protector
29.
23-6305
Rubber Ring, 2"
1.0.
30.
23-6303
Rubber Ring,
1-1/4" 1.0.
31.
23-6535
Rubber Bumper
32.
A-16651-9
Playfield Plastic Assembly
33.
31-1765-32
Playfield Plastic
34.
31-1765-33
Playfield Plastic
35.
RM-21-03
Tubing #10
36.
H-16502
Mini-Playfield Cable
37.
H-16603
Mini-Playfield Opto Cable
38.
4408-01118-00
Nut 8-32 Tee x
3/8
39.
4106-01115-06Y
sn,
Metal Screw, #6 x
3/8
PL-HWH-YEL
40.
4008-01005-32
Mach. Screw, 8-32 x 2 P-PH
41.
4106-01114-08
rcs
6 x
1/2
PLHWH-17
42.
4408-01119-01
Nut 8-32 ESNA
43.
4008-01005-28
Mach. Screw, 8-32 x 1-3/4P-PH
44.
4410-01132-01
Nut, 10-32 ESNA
45.
4700-00021-00
Flatwasher,
13/64
x
7116
x 21ga.
46.
4406-01119-00
Nut 6-32 ESN
47.
4106-01115-16
Sh. Metal Screw, 6 x 1" HWH
48.
4106-01013-10
Sh. Metal Screw, 6 x
5/8
P-PH
49.
03-8063-6
Sleeve, Yellow
50.
5070-09034-00
Diode, 1N4004
51.
20-9860
Cover Switch Protect
-....,-.-_.-
-
Twilight Zone 2-40
