Unique Parts List
Part Number
Description
Part Number
Description
.,'-..-. /
A-12742-50020
WPC CPU Board
A-16379
3-Switch & Bracket Assembly
A-13204-50020
Bottom Arch Assembly
A-16381
Loop Assembly
A-13769-50020
PJayfield & Insert Assembly
A-16391
Ball Guide Assembly
A-13769A-50020
Mini-Playfield & Insert Assy.
A-16416-1
Mini-Playfield Sw. & Brkt. Assy.
A-14375-2
Coil & Bracket Assembly
A-16416-2
Mini-Playfield Sw. & Brkt. Assy.
A-15896-2
Sw. Button & Cable Assembly
A-16433
Shooter Gate Assembly
A-12738-50020
Sound Board Assembly
A-16434
Kicker Assembly
A-16055
Front Molding Assembly
A-16495
Transformer Mtg. Plate Assembly
A-16056
Right Wire Chute Assembly
A-16514-1
4-Lamp Board Assembly
A-16058
Mini Inside Wire Chute Assy.
A-16515-1
3-Lamp Board Assembly
A-16059
X-Over Wire Chute Assembly
A-16516-1
3-Lamp Board & Spacer Assy.
A-16060
Main Ramp Assembly
A-16517-1
a-Lamp Board & Spacer Assy.
A-16062
Center Ramp Assembly
A-' 6518
Ball Guide Opto Assembly
A-16063
Right Diverter Brkt. Assembly
A-16519
Ball Guide & Switch Assy.
A-16064
Right Diverter Assembly
A-16520
Switch & Bracket Assembly
A-16100-1
8-Driver PCB & Spacer Assy.
A-16528
Trough-Coil Assembly
A-16114
Diverter Assembly
A-16533
Ball Sensor Assembly
A-16116-1
8-High Pwr Driver & Spacer Assy.
A-16534-1
Prox Opto Ssnscr & Spacer Assy.
A-16117-1
Cashbox Assembly
A-16535
Ramp Prox Opto Sensor Assy.
A-16119
Right Deflector Assembly
A-16536
Opto & Plate Assembly
A-16120-1
D.C. Motor Control & Spacer Assy.
A-8552-50020
Backglass Assembly
A-16123
Backbox Assembly
A-16806
Mini-Playfield Assembly
A-16124
Clock Assembly
A-16132
Gumball Machine Assembly
B-12445-6
Ball Shooter Assembly
A-16133
Main Chute Assembly
A-16164
Lock Up Ramp Assembly
01-11063
Deflector - Center
A-16170
Lock Up Trough Assembly
01-11064
Deflector - Left
A-16174
Shooter Ramp Assembly
01-11065
Deflector - Right
'---' ~'
A-16l8'
Ball Guide Assembly
01-11067
Deflector - Flipper
A-16182
Ball Guide Assembly
01-11162-1
Flipper Ball Guide - Right
A-16184
Ball Guide Assembly
01-11162-2
Flipper Ball Guide - Left
A-16185
Ball Guide Assembly
01-11216
Ball Guide, Mini-Playfield
A-16186
Ball Guide Assembly
01-11217
Ball Guide, Mini-Playfield
A-16188
Ball Guide & Opto Assembly
01-11218
Ball Guide, Mini-Playfield
A-16189
Ball Guide Assembly
01-11219
Ball Guide, Shooter
A-16190
Ball Guide & Opto Assembly
A-16201
Ball Guide Assembly
02-4436-25
F-F Spacer, 8-32 x 1-9/16"
A-16202
Ball Guide Assembly
02-4611-2
Post M-F 8-32 x 1.69 Hex.
A-16203-1
Flipper Ball Guide Assy., Right
02-4611-3
Post M-F 8-32 x 2.12 Hex.
A-16203-2
Flipper Ball Guide Assy., Left
02-4611-4
Post M-F 8-32 x 3.12 Hex.
A-16216
Rear Trough Assembly
A-16233
Ball Guide Assembly
03-8870-2
Plfd. Mylar - Small
A-16287
SpeakerlDisplay Assembly
03-8870-3
Plfd. Mylar - Small
A-16307
Eject Assembly
A-16312
Ball Popper Assembly
08-7028-1
Playfield Glass (Wide Body)
A-16313
Rear Diverter Assembly
A-16326
Mini-Playfield Exit Opto Assy.
11-1106
50020-Cabinet
A-16327-1
G.I.
&
Flash 19-Lamp Board
11-50020-IN
Wood Insert Panel
A-16328-1
6-Lamp Board
&
Spacer Assy.
11-831-50020
50020- Back Panel
A-16329-1
3-Lamp Board Assembly
A-16330
2-Flash Lamp PC Board Assy.
12-7059
Wire Chute - Right
A-16338
Shooter Diverter Assembly
12-7060
Wire Chute - Mini Feed
A-16354
Auto Shooter Opto Assembly
12-7061
Wire Chute - Mini Inside
A-1636l
Bridge Diverter Assembly
12-7062
Wire Chute - Cross Over
\..__,....
Twilight Zone 2-44
