UPPER PLAYFIELD PARTS LIST
lliun fla
Numb~[
Description
Not Shown:
'--- ---
1
01-11401
Playfield Hanger Brackets (2)
2
20-9250-6
Flipper & Shaft, Yellow
A-13204-50020
Bottom Arch Assembly
3
A-16203-2
Flipper Ball Guide Assy., Left
A-13769-50020
Screened Playfield
4
03-8318-16
Double Light Hood, Yellow
A-14632-2
Mounting Brkt. Clamp Assy.
1/2"
5
01-9510
#8 Post Adjustment Plate (2)
A-14632-3
Mounting Brkt. Clamp Assy.
3/4"
6
A-14691-6
Standup Target, Yellow
A-14632-4
Mounting Brkt. Clamp Assy. 1"
7
03-8254-16
Jet Bumper Cap, Yellow
A-16513
Bridge Diverter Gate
B-9414-3
Jet Bumper Assembly
A-1 6651-1
Playfield 'Plastic Assembly
A-12753-2
Lug & Diode Assembly
A-16651-2
Playfield Plastic Assembly
8
03-8254-9
Jet Bumper Cap, Red
A-16651-3
Playfield Plastic Assembly
B-9414-3
Jet Bumper Assembly
A-16651-4
Playfield Plastic Assembly
A-12753-2
Lug & Diode Assembly
A-16651-5
Playfield Plastic Assembly
9
03-8254-8
Jet Bumper Cap, Amber
A-16651-6
Playfield Plastic Assembly
B-9414-3
Jet Bumper Assembly
A-16651-7
Playfield Plastic Assembly
A-12753"2
Lug & Diode Assembly
A-16651-8
Playfield Plastic Assembly
10 A-16185
Ball Guide Assembly
A-8645
Wire Form & Bracket Assembly
11 A-16186
Ball Guide Assembly
B-8623
Runway Ball Guide wlBaffle
12 A-16184
Ball Guide Assembly
01-3569-1
Ball Return Runway
13 20-9264-6
Small Flipper & Shaft, Yellow
01-5575
Bottom Arch Mounting Brackets
14 01-11067
Flipper Deflector
01-10599
Runway Ball Guide, Long
15 01-11064
Left Deflector
01-10621
Strike Plate
01-11207
Impact Bracket
01-11426
Mini-playfield Support Bracket
16 01-11151
Ball Guide
01-11427
Mini-playfield Inner Bracket
17 A-16132
Gumball Machine
01-11428
Mini-playfield Outer Bracket
18 01-11164
Ball Guide Assembly
01-11429
Mini-playfield Rear Bracket
19 02-4611-4
Standoff 3
1/8"
01-11640
Ramp Guard Left
20 01-11186
Rear Deflector
01-11648
Ball Deflector
21 A-16164
Lock-up Ramp Assembly
01-11548
Ramp Guard Right
22 A-16785
Ball Guide Assembly
02-4335-8
Standoff 1
7/16"
23 A-16170
Lock-up Trough Assembly
12-6542
Runway Gate Wire
24 A-12258-2
#8-32 Stud Plate Assembly
31-1743
Shooter Gauge
'--_-
25 02-4436-10
Standoff 2
1/2"
50020-Plastic
Playfield Plastic Set
26 A-16796
Ball Guide Assembly
27 A-16124
Clock Assembly
*Twilight Zone has a special hardcoat playfield and
01-11063
Center Deflector
does not require a full mylar. However, mylars can
28 A-15658-2
Oblong Standup Target, Green
be purchased through your local Bally Distributor
29 A-14691-4
Standup Target, Red
(ref. #03-7960-50020-1).
30 A-16794
Ball Guide Assembly
31 A-16064
Right Diverter Assembly
32 A-16119
Right Deflector Assembly
33 02-4611-3
Standoff 2
1/8"
34 A-16174
Shooter Ramp Assembly
35 01-11581
Ball Guide
36 A-15658-6
Oblong Standup Target, Yellow
37
01-" 149
Ball Guide
38
01-11149
Ball Guide
39 20-9250-6
Ripper & Shaft, Yellow
40 A-16433
Shooter Gate Assembly
41 02-4611-2
Standoff 1 1
1116"
42 A-16751
Ball Guide Assembly
43 01-11518
Ball Guide
44 01-11219
Ball Guide, Shooter
45 12-6466-8
2" Wire Guide
46 A-16203-1
Flipper Ball Guide Assy., Right
47 20-9250-6
Ripper & Shaft, Yellow
48 A-16851
Ball Guide Assembly
49 A-15802-P
Level Assembly
50 02-4611-5
Standoff 1
1/4"
51 A-8039-3
Ball Release Assembly
< :>
Twilight Zone 2-48
