BRIGHT LIGHT FUSE BOARD. The Bright Light Fuse
Board is part number A080-91901-BOOO.This board in-
cludes 16 fuses. The fuses protect SCRs in the phase C
and phase D lamp drive circuits.
SOLID STATE RELAY BOARD. The Solid State Relay
Board is part number A080-91902-AOOO.This board controls
the large, incandescent, back box-illumination bUlb.
BOARDS NOT IN THE BACKBOX
. Two other boards are located on the playfield. Emitter
Board A084-91895-BOOOand Detector Board A084-91894-
BOOOare under the bottom arch. They optically detect balls
on the ball ramp.
CONTROL LOCATIONS
THE ON-OFF SWITCH is on the bottom of the cabinet, near
the right, front leg.
THE VOLUME CONTROL is inside the coin door. Look at
the left, inner wall of the cabinet, on the tilt mechanism
board.
THE CREDIT BUTTON is left of the coin door on the front
of the cabinet.
GAME ADJUSTMENT/DIAGNOSTIC SWITCHES. The
SELF TEST button switch is inside the coin door. This
switch assists you during game adjustments, bookkeeping,
and problem diagnosis. Details appear in Chapter 2.
INSTALLATION PROCEDURE
[ ] 1.0pen the shipping container. Remove cartons, parts
and other items. Set them aside.
,~
;</,<
ftI'
[] 2.Leg levellers and bolts are provided in the'casbbox. In-
stall levellers on the game's rear legs. Set the game on a
flat surface or dolly. Bolt the rear legs to the game. ,
1-4
