Notes:
I. Functions 00-11 cannot be changed from the coin door; however,
Functions 01-11 can be set to zero as described on labeladjacent to
CPU Board in backbox.
2. Total Credits (Function (8) is the sum of Function 04 and as
applicable, Functions OS, 06, and 07.
3.
Total Extra Balls (Function 09) is the sum of the game extra ball
feature and Functions 05 and 06, as applicable.
4. Current High Score to Date (Function 12) can be changed to the
value of the Backup High Score to Date (Function 13)by operating
. the HIGH SCORE RESET switch while in the game over mode.
5. Function 13 may be set to any multiple of .10,000points. Setting
Furiction 25 to zero with Function 13 set to any score but zero
permits the High Score to Date feature to operate but no credits are
awarded.
6. Functions 14-17 (Replay Scores) may be set to any multiple of
. 10,000 points. Setting a function to zero disables the replay score
point. Always disable the Replay
4
level first, the Replay
3
level
second, etc. The replay levels must be set with ascending values.
7.
Setting
Maximum Credits (Function 18)to zero places the game in a
free play mode.
8. With Function 19 set to 00, Functions 20-24 must be set manually.
Refer to Table 2 for seven standard pricing schemes (selected by
values of 01-07 for Function 19) and custom pricing values.
9. For 5 ball play, a setting of 00 for Function 32 is recommended.
RECOMMENDED SCORE,LEVELS
Levels
~:;;;'.ScoreCard
''t1'-
CREDIT GAMES·~:'"
3-Ball:
*270,000; 370,000; 470,000
or 230,000; 380,000
5-Ball:
(See Note 9)
390,000; 590,000
EXTRA BALL
.,.:..: •...
487-12
487-25
~
..
.
,
,.
\
487-41
3-Ball:
180,000; 280,000
5-BaIl:
300,000; 400,000
*Factory setting
487-68
487-69
