16-515-103
Game No. 515
December, 1982
INSTRUCTION BOOKLET
This booklet provides game operation, bookkeeping, game adjustment, diagnostic, and self-test procedures for
TIME FANTASY. For installation and special maintenance information referto th •
• game manual.
SPECIAL CONSIDERATIONS WHEN REPLACING CIRCUIT BOARDS
CPU Board
I. Revision level 7 CPU Boards (batteries located on lower left corner at board) of later boards must be used.
2. Must be equipped with blue-labeled Flipper ROMs and'-:
Game ROMs.
3. Jumpers W3, WIO, Wll, W14, W17, W19, W20, and W22 must be connected. Jumpers W4, W9, W12,
WI5, W16, W18, W21, and W23 must be removed. With the exception ofW25, (Factory Setting Jumper)
all other jumpers are not changed.
Driver Board
Must be equipped with zero-ohm resistors or wire jumpers (W9-WI6) in place of switch matrix drive series
resistors R204-R211.
Sound Board
Must be jumpered for ROM operation and be equipped with Sound ROM 13. (Jumpers W2, W5, W7, W9, WIO,
W12, and WI5 connected; W3, W4, W6, W8,
wu,
and W13 removed).
Power Supply Board
l. Model D 8345 board required (equipped with relay).
2. Fuse F4 (lOA SB) for flipper solenoids must be installed.
Display Boards
Model C 8363 Master Display and 7-digit Slave Displays required.
Game Operation
Game Over Mode - Turn game ON; player I score shows 00; all player scores alternate the high score to date,
Game Over lamp lights. All playfield lamps cycle in attract mode.
Credit Posting - Insert coins; sound produced, number of credits displayed. If maximum credits* exceeded by
coin or high score to date, credits posted correctly and coin lockout de-energizes until remaining credits are
below maximum. No credits may be won and coins are rejected while the coin lockout is de-energized.
Game Start - Push credit button; start-up tune played, ball served, credit display reduced by one, player I up_
flashes until first scoring switch is made, ball in play shows l. Pushing credit button before ball 2 is displayed
allows second player.
*Indicates adjustable features.
/..aM
Change
is a trademark of Williams Electronics, Inc.
