A-17932
Disappearing Post Assembly
Item Part Number
Description
1 01-12441
Divener Post Bracket
2 03-7067-5
Coil Tubing
3 01-8-508-T
Coil Retainer Bracket
4 AE·27·1200
Coil Sub-Assembly
5 10-135
Spring
6 A-17986
Bell Armature Assembly
7 23-6420
Rubber Grommet
8 4008-01 017 -04 Mach. Screw, #8-32 x 1/4"
A-17796
Ball Gate Actuator Assembly
Item
Part Number
Description
1 01-12348
Ball Gate Coil Bracket
2 A-14406
Coil Assembly
3 A-11146
Armature Assembly
4 A-6892
Frame & Eyelet Assembly
5 10-120
Spring
6 4701-00003-00 lockwasher #8 Split
7 4700-00089-00 Flat Washer, 11/64 x 7/16 x 16ga.
8 4008-01021-07 Mach. Screw, 8-32 x 7/16
9 10-194
Extension Spring
2-23
