A-18543-1
Generic Eddy Sensor PCB Assembly
Part Number
5370-13452-00
5190-10270-00
5160-10269-00
5010-08992-00
5010-09807-00
5010-09034-00
5010-09999-00
5671-13732-00
5070-08919-00
5791-13830-04
5791-13830-02
5041-09031-00
5010-08991-00
5048-13658-00
5014-10261-00
Designator
Ul
02
01,03
R4
R3
R7
R5,R6,R8
LEOl
01,02,03
Jl
J2
C4
Rl
Cl, C2
R2
Description
IC Proximity Sensor
Transistor 2N3906 PNP
Transistor 2N3904 NPN
Resistor, 560Q,
1/4w,
5%
Resistor, 120Q,
1/4w,
5%
Resistor, 10Kll, 5%,
1/4w
Resistor, 2Kll,
1/4w, 5%
Display LED Red
Diode 1N4148 150mA
Connector, 4-pin Header .100 Solid Tab
Connector, 2-pin Header .100 Solid Tab
Capacitor, 1M, 25v(±20%)Axial
Resistor, 4.7K,
1/4w,
5%
Capacitor, 3300PF, 100v (%5%) Cog.
Pot 10K,
1/4w
(±20%)
A-18543-2
Generic Eddy Sensor PCB Assembly
Part Number
5370-13452-00
5190-10270-00
5160-10269-00
5010-08992-00
5010-09807-00
5010-09034-00
5010-09999-00
5671-13732-00
5070-08919-00
5791-13830-04
5791-13830-02
5041-09031-00
5014-10261-00
5043-10267-00
5043-09065-00
Designator
U1
02
01,03
R4
R3
R7
R1, R5, R6, R8
LEOl
01,02, D3
Jl
J2
C4
R2
C2
Cl
Description
IC Proximity Sensor
Transistor 2N3906 PNP
Transistor 2N3904 NPN
Resistor, 560Q,
1/4w,
5%
Resistor, 120Q,
1/4w,
5%
Resistor, 10Kll, 5%,
1/4w
Resistor, 2Kll,
1/4w, 5%
Display LED Red
Diode 1N4148 150mA
Connector, 4-pin Header .100 Solid Tab
Connector, 2-pin Header .100 Solid Tab
Capacitor, 1M, 25v(±20%)Axial
Pot 10K,
1/4w
(±20%)
Capacitor, 150PF, l00v Ceramic Axial
Capacitor, 470P, 50v (±20%)
o
:D
L
N
o
~D
Pl
o
Q2
o
A·18543·1 and A·18543·2 Generic Eddy Sensor PCB
2-13
