A-18617-1
Trough IRED LED PCB Assembly
OLEDI
o
o
o
LED3
o
0
Part Number
Designator
Description
5671-12731-00 LE01 - LE05 Infra Red Diode
5791-12622-09 J1
Connector, 9-pin Header Sq.
A-18618-1
Trough IRED Transistor PCB Assembly
o
o
05
o
o
Q4
o
Part Number
Designator
Description
5163-14114-00 01 - 05
Infra Red PhotoTransistor
5791-12622-09 J1
Connector, 9-pin Header Sq.
2-11
