BASEMENT
I
TRAPDOOR ASSEMBLY
The Basement and Trapdoor mechanism is located under the playfield. Balls are carried from the Magic
Trunk into the locking trough area thru a plastic chute. Players can also shoot into the trapdoor from
above, when the door is up.
The assembly uses 3 coils to function. A release coil (1) shuttles balls into the popper. The trap door is
then raised by the lift coil (2) and the ball is kicked out into play by the popper (3).
Spring Mounted Lid
Trapdoor
Lid Assembly
Popper Assembly
Trapdoor
Release Collar
(1) Release Coil
(2) Trapdoor
Lift Coil
(3) Popper Coil
Coil Brocket
FIG.
1
Side View
1-47
