Lower Playfield Parts
Item Part Number
Description
1 01-9211
Plfd. Hanger Bracket Assy. (2)
2 01-13645
Leg Support (2)
3 A-19963
Outhole Ball Trough Assembly
4 A-15849-R-2 Flipper Assembly, Lwr. Right
5 A-15595
7-Switch Opto PCB & Bracket
6 A-17811
Kicker Arm (Slingshot) Assembly
B-9362-R-4
Coil & Bracket Assembly
7 A-15257
Bracket & Pole Piece Assy. (2)
8 20-10197
Coil Magnet & Coil Breaker (2)
9 A·19982
ts-tamp Board Assembly
10 A·19939
Plate Assembly· Complete
11 A·19984
6·Lamp Board Assembly
12 A·16120
D.C. Motor Control PCB Assy.
13 A·9415·2
Jet Bumper Coil Assembly
14 A·17749.1·2
Slide Playfield Assembly, Right
15 A-17796
Ball Gate Actuator Assy. (2)
16 A·20003
Eject Assembly
17 A-17932
Disappearing Post Assembly (2)
18 A·17749.1-1
Slide Playfield Assembly, Left
19 A·19782
Magic Trunk Motor Assembly
20 A·18543·2
Generic Eddy Sensor PCB
21 A·19825
Trough Assembly
22 A·19983
17·Lamp Board Assembly
23 A-18543·1
Generic Eddy Sensor PCB (2)
24 A·17811
Kicker Arm (Slingshot) Assembly
B·9362-L-3
Coil & Bracket Assembly
25 A·19981
14·Lamp Board Assembly
26 A-15849-L-2
Flipper Assembly, Lwr. Left
27 A-20036
Eddy Coil PCB Assembly
28 A·17064
Inductor & Eddy Sensor Cable (2)
