A-20003
Eject Assembly
Item Part Number
Description
1 01-13852
Eject Bracket
2 23-6420
Rubber Grommet
3 A-15371
Plunger Assembly
4 10-135
Spring
5 03-7067-5
Coil Tubing
6
01-8-508-T
Solenoid Bracket
7 4008-01017-04 Mach. Screw, 8-32 x 1/4"
8 AE-27-1200
Coil Assembly
A-19938
SCOOpAssembly - Complete
Item Part Number
Description
1
2
3
4
5
*6
04-10022
04-10020.1
10-392
4700-00073-00
12-6227
31-2255-4
Scoop Assembly
Flap Assembly
Spring
Flat Washer, 9/32
x
1/2
x
21ga.
Hairpin Clip
Decal
*
Not available for individual sale. Order Decal Set 31-2255.
2-28
