A-19963
Outhole Ball Trough Assembly
.Imm
part Number
Description
.IU.m
part Number
Description
1 A-16809-2
Ball Trough Welded Assy.
11 4008-01017-05 Mach. Screw. 8-32 x 5/16'
2 01-11587
Ball Trough Front
12 4408-01119-00 Nut 8-32 ESN
3 A-6306-2
Bell Armature Assembly
13 4008-01017-06 Mach. Screw. 8-32 x 3/8'
4 AE-26-1500
Coil Assembly
14 23-6702
Bumper Plug
5 01-8-508- T
Solenoid Assembly
15 A-18617-1
Trough IRED LED PCB Assembly
6 03-7067-5
Coil Tubing
16 A-18618-1
Trough IRED Transistor PCB Assy.
7 10-135
Spring
17 4006-01003-10 Mach. Screw, 6·32 x 5/8' SEMS
8
23-6420
Rubber Grommet
18 23-6626
Rubber Grommet
9 03-8523
Insulator
19 4700-00004-00 Flat Washer, 9/64 x 7/16 x 21ga.
10 01-11586
Coil Mounting Brkt. (Bell)
20 02-4975
Bushing
2·19
