A-18617-1
Trough IRED LED PCB Assembly
OLEDI
o
o
o
LED3
o
0
Part Number
Designator
Description
5671-12731-00
LED1 - LED5 Infra Red Diode
5791-12622-09
J1
Connector, 9-pin Header Sq.
A-18618-1
Trough IRED Transistor PCB Assembly
o
o
05
0
o
04
o
Part Number
Designator
Description
5163-14114-00
Q1 - 05
Infra Red PhotoTransistor
5791-12622-09
J1
Connector, 9-pin Header Sq.
2-11
