8ackbox Assembly
/-
.....•
(
('\
\
.
\
~
/
'---------'
<: :»:
/---
(.:'
\
\.
/
'T'-
?
Miscellaneous Parts
Item Part Number
Description
1 01-6645
Venting Screen
2 8-10686-1
Knocker Assembly
3 A-12497
Insert Bd. Hinge Assy., Upper
4 A-14092-5
WPC Mounting Plate Assy.
5 A-12498
Insert Bd. Hinge Assy., Lower
6 A-12697-3
Power Driver Assembly
7 A-16917-50039
Sound Board Assembly
8
A-17651-50039
WPC Security CPU Board
9 04-10012-50039 Backbox, Wood
10 01-9047
Insert Stop Bracket
11 A-19748
Speaker/Display Assembly
12 A-14039.1
Dot Matrix Controller Board
13 A-13379
Lock & Plate Assembly
14 50039-IN
Insert Board
15 A-15472-1
Fliptronic II Board
RibbonCables
16 5795-12653-03
Ribbon Cable, 3"
17 5795-13018-01
Ribbon Cable, 23.5"
18 5795-10938-15
Ribbon Cable, 15"
19 5795-13434-32
Ribbon Cable w/Ferrite 32"
2-2
Part Number
A-8552-50039
03-8228-2
03-8228-3
03-8229-1
08-7456
20-9718
31-1357-50039
Backbox Cables
H-14584
H-15476
H-15736-1
H-19997
Description
Tempered Backglass Assy.
Glass Channel Top (1)
Glass Channel Edge (2)
Glass Lift Channel (1)
Backbox Glass: 27 x 18-7/8'
Wing Screw, 3/8-16 x 2"
Screened Translight
Dot Matrix Display Power Cable
Logic Power Cable
Secondary Cable
Insert Cable
