Page 72 - Theatre of Magic

Remove the Trapdoor Lid
1) To remove the Trapdoor lid, raise the trapdoor shaft and thru the access hole loosen and take out the
screw fastener on the Release Collar.
2) Gently lift the lid assembly up and out of the playfield.
(2) Lid Assy
Lock Switches
8011 Locking Trough
Boll Release Coil Assy.
Bal Popper Switch
FIG. 2 Front View
1-48
(1) Remove fastener
on Release Collar
Trapdoor Roise Coil
Shoft Assy
