Fliptronic II Board
A-15472-1
J902
113
1°00000000*00°1
J903
,- J
0
I
0
I
i'-
*
0
0
m
0
-:>
0
0
0
~'"
J904
J905 J906
~ lL_
___JI~;
1
0 0
*
0 0
I
5
1
J901-1 White-Blue, 50VAC from J104-1
J901-2 White-Blue, loop from J901-1
J901-3 White-Blue, SOVAC from J104-2
J901-4 Key
J901-S White-Blue, loop from J901-3
J902-1 Not Used
J902-2 Not Used
J902-3 Yellow-Gray,
Sol
35
to playfield magnet
J902-4 Orange-Violet,
Sol
34
to playfield coil
J902-S Not Used
J902-6 Yellow-Violet,
Sol
33
to playfield magnet
J902-7 Orange-Blue, holding lower left flipper
J902-8 Not Used
J902-9 Yellow-Blue, power lower left flipper
J902-10 Key
J902-11 Orange-Green, holding lower right flipper
J902-12 Not Used
J902-13 Yellow-Green, power lower right flipper
J903 Ribbon Cable, data to/from J202; JS06; J601
J904-1 Gray, +SV to/from J114-4; J210-4
J904-2 Gray-Green, + 12V to/from J114-2; J210-6
J904-3 Key
J904-4 Black, Ground to/from J114-7; J210-1
J904-5 Black, Ground to/from J114-5; J210-3
J905-1 Black-Violet, to right flipper opto
J905-2 Blue-Gray, to left flipper opto
J90S-3 Black-Yellow, to right flipper opto
J905-4 Key
J905-5 Black-Blue, to left flipper opto
J90S-6 Orange, Switch Ground
J906-1 Black-Green, to lower right E.O.S. switch
J906-2 Key
J906-3 Black-Blue, to lower left E.O.S. switch
J906-4 Not Used
J906-5 Not Used
J906-6 Orange, Switch Ground
J907-1 Red-Green, +50V to lower right flipper
J907-2 Red-Green, loop from J907-1
J907-3 Key
J907-4 Red-Blue, +SOV to lower left flipper
J907-5 Red-Blue, loop from J907-4
J907-6 Red-Violet, +SOV to upper right flipper
J907-7 Red-Violet, loop from J907-6
J907-8 Red-Gray, +50V to upper left flipper
J907-9 Red-Gray, loop from J907-8
3-25
