Lower Playfield Parts
Item Part Number
Description
1 01-9211
Plfd. Hanger Bracket Assy. (2)
2 01-13645
Leg Support (2)
3 A-19963
Outhole Ball Trough Assembly
4 A-15849-R-2 Flipper Assembly, Lwr. Right
5 A-15595
7-Switch Opto PCB & Bracket
6 A-H811
Kicker Arm (Slingshot) Assembly
B-9362-R-4
Coil & Bracket Assembly
7 A-15257
Bracket & Pole Piece Assy. (2)
8 20-10197
Coil Magnet & Coil Breaker (2)
9 A-19982
18-Lamp Board Assembly
10 A-19939
Plate Assembly - Complete
11 A-19984
6-Lamp Board Assembly
12 A-16120
D.C. Motor Control PCB Assy.
13 A-9415-2
Jet Bumper Coil Assembly
14 A-17749.1-2
Slide Playfield Assembly, Right
15 A-17796
Ball Gate Actuator Assy. (2)
16 A-20003
Eject Assembly
17 A-17932
Disappearing Post Assembly (2)
18 A-17749.1-1
Slide Playfield Assembly, Left
19 A-19782
Magic Trunk Motor Assembly
20 A-18543-2
Generic Eddy Sensor PCB
21 A-19825
Trough Assembly
22 A-19983
17-Lamp Board Assembly
23 A-18543-1
Generic Eddy Sensor PCB (2)
24 A-17811
Kicker Arm (Slingshot) Assembly
B-9362-L-3
Coil & Bracket Assembly
25 A-19981
14-Lamp Board Assembly
26 A-15849-L-2
Flipper Assembly. Lwr. Left
27 A-20036
Eddy Coil PCB Assembly
28 A-17064
Inductor & Eddy Sensor Cable (2)
