A-20084
Ball Shooter Assembly
Associated Parts:
Item Part Number
1 20-9927-1
2 10-149
3 4700-00051-00
4 21-6645-1
5 03-7357
6 10-148
7 20-8714-37
8 23-6327
Description
Item Part Number
Description
Ball Shooter Rod w/Shaft
Outer Spring
Flat Washer,
25/64
x 5/8 x 16ga.
Shooter Housing
Shooter Sleeve
Power Spring
External Retainer Ring
Ball Shooter Tip
9 01-3535
Rod Mounting Bracket
10 4010-01006-10 Mach. Screw, 10-32 x
5/8"
2-29
