8ackbox Assembly
t-------{
11
• Ribbon Cables
Item Pad
~ymber
Description
Item Pad Number
Description
1 01-6645
Venting Screen
16 5795-12653-03 Ribbon Cable, 3"
2 B-10686-1
Knocker Assembly
17 5795-13018-01 Ribbon Cable, 23.5"
3 A-12497
Insert Bd.Hinge Assy., Upr.
18 5795-10938-15 Ribbon Cable, 15"
4 A-14092-6
WPC Mounting Plate Assy.
19 5795-13434-32 Ribbon Cable w/Ferrite 32"
5 A-12498
Insert Bd. Hinge Assy., Lwr.
6 A-12697-3
Power Driver Assembly
7 A-16917-50032 Sound Board Assembly
8 A-17651-50032 WPC Security CPU Board
• Miscellaneous Parts
9 A-19031
Backbox, Screened
10 01-9047
Insert Stop Bracket
A-8552-50032 Tempered Backglass Assy.
11 A-19032
Speaker/Display Assembly
03-8228-2
Glass Channel Top (1)
12 A-14039.1
Dot Matrix Controller Board
03-8228-3
Glass Channel Edge (2)
13 A-13379
Lock & Plate Assembly
03-8229-1
Glass Lift Channel (1)
14 50032-IN
Insert Board
08-7456
Backbox Glass:27x18-7/8"
15 A-15472-1
Fliptronic II Board
31-1357-50032 Screened Translight
