Sound Board
A-16917-50036
P1 34-pin Ribbon Cable data to/from J601; J903; J202
/O~ODI
1
J3
5
J3-1
Gray +5V from
J114-4;
J904-1; J210-4
J3-2
Key
J3-3
Gray +5V from
J114-3;
J210-5
J3-4 Black ground from J114-7; J904-4; J210-1
J3-5
Black ground from J 114-5; J904-5;
J21 0-3
J1-1
Black-Yellow signal to cabinet speaker
J1-2
Not Used
J1-3
Key
J 1-4 Black ground
rn
~
c,
...
•
o
-
J2-1
Black-Yellow signal to display panal speakers
J2-2
Key
J2-3
Not Used
J2-4 Black ground
00 ·
;:;,
-
J4-1
Gray-Green 18VAC from xfrmr secondary
J4-2 Gray-Green 18VAC loop from
J4-1
J4-3
Key
J4-4
Gray 18VAC from xfrmr secondary
J4-5
Gray 18VAC loop from
J4-4
J4-6
Gray-White 18VAC from xfrmr secondary
J4-7 Gray-White loop from J4-6
Speaker Wiring Diagram
:~ ----:
G~1-'
----I
I ~ III
I
L
5ABINEI_ __
J
I
I
I
SOUND
I
1---------1
I
BOARD
I
I I
I
I I
I
I
I I
I
L
J
I
I
I
I
I
I
I
-
I
LSPEAKER_PANI_L
_j
J2
3-31
